Toyotomi FF 55T Operation Instructions Manual

Vented heating system type b
Hide thumbs Also See for FF 55T:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
FF_55T_Type B_US.qxd 14.5.29 15:58 ページ a
MODEL
IMPORTANT
1) READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER.
2) RETAIN INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
3) CHECK LOCAL AUTHORITY & BUILDING CODES FOR INSTALLATION REQUIREMENTS.
Specifications ··························································· 1
Safety Features ························································· 2
Safety Tips for Operation ·········································· 3
Fuel Guide ································································· 4
Operating Controls and Part Names ························· 5
Before Ignition ························································ 7
Operation ································································ 9
Turning Heater Off ·············································· 14
VENTED HEATING SYSTEM
OPERATION INSTRUCTIONS
FF 55T
(Type B)
Page No
CONTENTS
Routine Maintenance ·············································· 15
Troubleshooting ······················································ 17
Long Term Storage ················································· 18
Standard Installation Parts ··································· 19
Optional Accessory Parts ····································· 20
Installation Advice ················································ 24
Installation of Heater and Flue Pipe ····················· 25
Page No

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FF 55T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyotomi FF 55T

Summary of Contents for Toyotomi FF 55T

  • Page 1: Table Of Contents

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ a VENTED HEATING SYSTEM OPERATION INSTRUCTIONS FF 55T MODEL (Type B) IMPORTANT 1) READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER. 2) RETAIN INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE. 3) CHECK LOCAL AUTHORITY & BUILDING CODES FOR INSTALLATION REQUIREMENTS.

  • Page 2: Section A

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 1 SECTION A: SPECIFICATIONS Model: FF 55T Heater Efficiency: 92.4% (1) Heat Rating: High - 5.50 kW (18,800 BTU/h) Med - 3.74 kW (12,800 BTU/h) Low - 1.88 kW ( 6,430 BTU/h) Fuel Consumption: High - 0.622 L/h Med - 0.423 L/h...

  • Page 3: Safety Features

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 2 SAFETY FEATURES Your heater is equipped with a number of integral safety features. Please familiarize yourself with these features. If the heater shuts down due to the operation of any safety device, ensure the problem is identified and corrected. Note that normal combustion flames inside the combustion chamber, can be seen through a “peep hole”, located in the front bottom left hand corner of the hot air outlet louver’s.

  • Page 4: Section B

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 3 SECTION B: SAFETY TIPS FOR OPERATION CAUTION: Heater and vent pipe system must be properly installed before operation. Please follow instructions under “Installation”, Section I. RIGHT WRONG Danger PARAFFIN PARAFFIN 1. NEVER use any fuel other than Paraffin. NEVER USE GASOLINE. Use of gasoline can lead to uncontrollable flames, resulting in destructive fire.

  • Page 5: Section C

    SECTION C: FUEL GUIDE The FF 55T is designed for use with Paraffin. Use of low-quality fuel will cause burner performance to drop, leading to abnormal combustion and reduced heater life. Purchase only Paraffin, in non-red cans reserved exclusively for fuel and marked accordingly with the word “PARAFFIN”.

  • Page 6: Section D

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 5 SECTION D: OPERATING CONTROLS AND PART NAMES Before using heater, familiarize yourself with the following operating controls and part names. Ciraulation air filter 16. Circulation fan Control panel Front panel Combustion flames peep hole 17.
  • Page 7 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 6 1. ON/OFF switch: Main switch turns heater on and off. When switched on, heater begins operation and combustion starts after preheat period. 2. AUTO button: The button turns weekly timer operation modes on and off which have been programmed into weekly timer.

  • Page 8: Section E

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 7 SECTION E: OPERATION BEFORE IGNITION 1: Filling Fuel • Do not fill the removable tank in the living room, but in a more suitable place (there can always be some spillage). • Do not refuel the heater while in operation or still hot. Follow the procedure below: 1) Make sure that the heater is switched off.
  • Page 9 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 8 4. Setting of the Time and a Day of the Week. 1) Current time is not set yet. (All signs light.) Press the “▲MIN.” button or “▼HOUR” button while in not operation. (Power switch is off.) 0:00 (midnight) is indicated on the display.

  • Page 10: Operation

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 9 OPERATION MANUAL OPERATION Operation of the heater is under the direct control of the user. Heat output will, however, be automatically adjusted in accordance with the room temperature registered by the temperature sensor. 1. Turning Heater ON A.
  • Page 11 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 10 POWER SAVER OPERATION The Power Saver mode reduces the frequency of ignition actions, to save electric consumption. Press the POWER SAVER (DAY SELECT) button “ON” while in operation to start the operation of the “POWER SAVER”.
  • Page 12 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 11 1. Set the Weekly Timer NOTE: The following programs are set at the factory in advance. Program # Clock Time Temp. 6:00 20˚C (68˚F) “MON” “TUE” “WED” “THU” “FRI” 8:30 16˚C (62˚F) “MON” “TUE” “WED” “THU” “FRI” 17:00 20˚C (68˚F) “MON”...
  • Page 13 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 12 2) Set the timer The timer time is shown on the display. (In case that the timer time is not set, the bars are shown on the display.) Press the “▲MIN.” button or the “▼HOUR” button to set timer time. “0:00” will be shown on the display. (The all signs except the colon will blink.) When pressing the “▼HOUR”...
  • Page 14 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 13 2. Activate Weekly Timer Operation During operation (in a SW/ON position), press the “AUTO” button to enter the weekly timer operation mode. The “AUTO” sign will be shown on the display. However, if no program is set, you can hear the beep sound and cannot enter the weekly timer operation mode.

  • Page 15: Turning Heater Off

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 14 POWER FAILURE RECOVERY SYSTEM If at any time a power failure occurs during operation, heater will turn off. When the power returns, the unit will automatically restart with the following conditions. Please reset each setting when the settings are erased as indicated below.

  • Page 16: Section F

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 15 SECTION F: ROUTINE MAINTENANCE CAUTION: Be sure to disconnect heater before performing any checks or cleaning. CAUTION: Allow heater to cool completely before cleaning or maintenance. FOR OPTIMUM HEATER PERFORMANCE, THE PARTS SHOWN BELOW SHOULD BE CLEANED REGULARLY: Ciraulation air filter Circulation fan Louver...
  • Page 17 This inspection should include: a combustion check; flue pipe check; burner assembly check; cleaning all necessary parts and replacing gaskets as needed. Please ask your authorized TOYOTOMI dealer for details and scheduling. AUTOMATIC IGNITER CLEANING SYSTEM The igniter cleaning mode prolongs the igniter life.

  • Page 18: Section G

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 17 SECTION G: TROUBLESHOOTING BEFORE REQUESTING A SERVICE CALL The following symptoms are normal during operation of the heater. CONDITION REASON White smoke or smell inside home when the heater Machine oil used in factory assembly, or transit is first used.

  • Page 19: Section H

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 18 SECTION H: LONG TERM STORAGE At the close of each heating season, or when you do not plan to use your heater for an extended period, the following procedures are recommended. As the end of the season approaches, calculate your fuel purchases so that you can use up all the fuel you have on hand.

  • Page 20: Section I

    STANDARD INSTALLATION PARTS The following standard installation parts are enclosed with heater. For alternate installation methods, you may need to purchase additional accessories which are available from your TOYOTOMI dealer. See “Accessory Parts”. Wall Bracket (2 sets) (PART #17212589) Tapping Screw (1) (PART #17208678)

  • Page 21: Optional Accessory Parts

    OPTIONAL ACCESSORY PARTS Only use genuine Toyotomi parts and accessories, makeshift parts can affect safety and reduce performance. The Flue Pipe must be used in every installation, and cannot be installed other than through a wall, and with a slight “fall”...
  • Page 22 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 21 Total length of extension pipe between heater and Flue Pipe must be no greater than 3 m. No more than three bends may be used in extension pipe. Pipe Support Hardware L-Shaped Exhaust Joint 90 mm PART #17206004 PART #17187098...
  • Page 23 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 22 EXTENSION PIPE KIT EXTENSION PIPE KITS: L, M and S are designed to extend both Supply and Exhaust Pipes from the back of the heater to the Flue Pipe which is the only approved method of transporting hot flue gasses through a wall. The extension pipes must be installed “exposed surface mounted”...
  • Page 24 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 23 Extension Pipe Kit (M) PART #17206012 Extension Pipe Kit (S) PART #17206011 Max. 1000 mm ~ Min. 570 mm Max. 500 mm ~ Min. 320 mm 90 mm 90 mm (# 17187098) (# 17212685) (# 17187098) (# 17212685) (# 17206027)

  • Page 25: Installation Advice

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 24 INSTALLATION ADVICE Intake air and exhaust flue pipe openings of the Flue Pipe must be fully exposed to outside. The Flue Pipe must not vent into a chimney, garage, basement, under-floor or ceiling cavity, or any enclosed area, or be installed vertically, because the Flue Pipe is a “Heat Exchanger”...

  • Page 26: Installation Of Heater And Flue Pipe

    Hebel, Linear, Gibraltar and Plaster Board, Tiles, Weatherboard, Plastered Polystyrene, and metal profiles etc. The FF 55T heater is designed to be operated at altitudes up to 900 m, above sea level. For installation at alti- tudes between 900 m and 1800 m, adjustments by authorized serviceperson is necessary. Consult your sup- plier for advice.

  • Page 27: Extension Wire Of Room Temperature Sensor

    FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 26 EXTENSION WIRE OF ROOM TEMPERATURE SENSOR A room temperature sensor is located on the right side of the cabinet in front. The room temperature sensor is installed in the sensor case. When the room temperature cannot be reached at the desired temperature depending on the installation situation, the extension wire (*optional) is available to change the location.
  • Page 28 FF_55T_Type B_US.qxd 14.5.29 15:58 ページ 27 TOYOTOMI CO., LTD. 5-17, Momozono-cho, Mizuho-ku, Nagoya, Japan Printed in Japan http://www.toyotomi.jp New 06/14 8374002060...
