Page 1: Table Of Contents
VENTED HEATING SYSTEM INSTALLATION AND OPERATION INSTRUCTIONS Oil Miser 23 MODEL (Type E) IMPORTANT READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CHECK LOCAL CODES AND ORDINANCES FOR PERMITTED USE. CONTENTS SECTION A: SECTION G: Troubleshooting ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯...
Page 2: Section A
SECTION A: SPECIFICATIONS Model: Oil Miser 23 Heater Efficiency: 90% (1) Heat Rating: High 22,000 BTU/h 15,000 BTU/h 8,000BTU/h Fuel Consumption: High 0.165gal/h 0.113gal/h 0.060gal/h Fuel system: Gravity Fed from Reservoir / Tank (2) Fuel Type: ASTM D3699 1-K Kerosene, ASTM D396 Low Sulfur No.1 Fuel Oil, or ASTM D975 Ultra Low Sulfur Diesel (ULSD) (3) Dimensions (W ×...
Page 3: Section B
SECTION B: SAFETY TIPS FOR OPERATION CAUTION: Heater and vent pipe system must be properly installed before operation. Please follow instructions under “Installation”, Section I. Never use any fuel other than ASTM D3699 1-K Kerosene, ASTM D396 Low RIGHT WRONG Sulfur No.1 Fuel Oil, or ASTM D975 Ultra Low Sulfur Diesel (ULSD).
Page 4: Section C
FUEL GUIDE The Oil Miser 23 is designed for use with ASTM D3699 1-K Kerosene, ASTM D396 Low Sulfur No.1 Fuel Oil, or ASTM D975 Ultra Low Sulfur Diesel (ULSD). Use of low-quality fuel will cause burner performance to drop, leading to abnormal combustion and reduced heater life.
Page 5: Section D
SECTION D: OPERATING CONTROLS AND PART NAMES Control panel Front panel Louver Reset button Fuel strainer (inside) Drip tray Ciraulation air filter 12. Circulating fan Rear cover (upper) Rear cover (right) Rear cover (left) 13. Room temperature sensor Fuel inlet Pipe stopper Outlet opening 14.
Page 6 ON/OFF switch: Main switch turns heater on and off. When switched on, heater begins operation and combustion starts after preheat period. Power Saver button: The button turns Power Saver operation mode on and off. Timer button: The button turns Timer operation mode on and off. Temp./ Timer/Clock set: Temp./Timer/Clock set modes can be set by pressing UP/HOUR or DOWN/MIN buttons.
Page 7 REF # PART # PART NAME REF # PART # PART NAME REF # PART # PART NAME 2 0 4 7 9 8 2 7 Front panel (Type A) 2 0 4 7 9 5 7 3 Burner thermistor 2 0 4 7 4 1 6 6 Nut B 2 0 4 7 9 8 2 8...
Page 8: Section E
SECTION E: OPERATION BEFORE IGNITION Open the Valve(s) Reset button Open the valve(s) of the external fuel tank. Start the Fuel flow If using heater for the first time, press the red reset button in order to send fuel to the fuel sump and release. Note: Make sure there is no fuel leakage from the fuel line or joints.
Page 9 Turn Heater ON A. Press ON/OFF switch to “ON” position. The current room temperature and the set temperature will be shown on the digital indicator. POWER lamp will start to flash and then blower motor and ignition will start. This lamp will continue to flash during the preheating time. B.
Page 10 (set by user) by pressing a timer button. This button must be pushed each time you want the temperature to drop back. It is not automatic. There are two timer buttons on the Oil Miser 23, 1st timer and 2nd timer. This allows for two different temperature drop backs per 24 hour period.
Page 11: Turning Heater Off
Setting 1st Timer/2nd Timer: 1. Make sure the clock is set. If not, press the hour and minute button until the correct time is indicated. 2. Press 1st Timer button. Use the up and down arrows to set the time at which you want the room to return to normal temperature.
Page 12: Section F
SECTION F: ROUTINE MAINTENANCE CAUTION: Be sure to unplug heater before performing any checks or cleaning. CAUTION: Allow heater to cool completely before cleaning or maintenance. FOR OPTIMUM HEATER PERFORMANCE, THE PARTS SHOWN BELOW SHOULD BE CLEANED REGULARLY: Ciraulation air filter 13.
Page 13 Clean Fuel Strainer (ONCE A MONTH) Oil catch The strainer of the fuel sump should be cleaned once a month and before storing heater at the end of each season. (a) Close the valve(s) of the separate fuel tank. (b) To catch the fuel which will drain out, set the oil catch below the strainer cover, with a small container under it.
Page 14: Section G
SECTION G: TROUBLESHOOTING NOTE BEFORE REQUESTING REPAIR AND SERVICES The following symptoms are normal during operation of the heater. CONDITION REASON White smoke or smell at initial use after pur- Machine oil or dust burns off the surfaces of chase. the burner or heat exchanger.
Page 15: Section H
SECTION H: LONG TERM STORAGE At the close of each heating season, or when you do not plan to use your heater for an extended period, the following procedures are recommended. As the end of the season approaches, calculate your fuel purchases so that you can use up all the fuel you have on hand.
Page 16: Section I
SECTION I: INSTALLATION TOOLS NEEDED FOR INSTALLATION Tool Phillips Head Screwdriver Installation of flue pipe, etc. Electric Drill Drilling hole in wall for flue pipe Hole Saw, 2- to 3“ diameter Making hole in wall for flue pipe STANDARD INSTALLATION PARTS The following standard installation parts are enclosed with heater.
Page 17 15-3/4¨ Flue Pipe (1) (PART #20479891) Exhaust Air Cap (1) (PART #20479845) Intake Air Cap (1) (PART #20474949) Inlet Hose (1) (PART #20474951) 6-5/16¨ Bent Joint (1) (PART #20479884) L-Shaped Hose (2) (PART #20474975) Oil Catch (1) (PART #20474925) Hose Band (2) (PART #20474977) 10-5/8¨...
Page 18: Accessary Parts
ACCESSORY PARTS The following accessory parts are available for use of the Oil Miser 23. After giving careful consideration to your desired heater and flue pipe locations and fueling system, consult your TOYOSTOVE dealer to purchase the necessary accessory parts.
Page 19 EXTENSION KIT Extension Pipe Kit (L) PART #20479898 INSTALLATION WITH EXTENSION PIPE KIT (L) Max. 39- ~ Min. 22- inch (# 20479853) (# 20479861) (# 20474963) (# 20474950) inch Pipe Support Hardware (# 20479872) Pipe Holder (2 pcs.) 80 inch Adjustable Exhaust Pipe Intake Hose...
Page 20 Extension Pipe Kit (M) PART #20479897 Extension Pipe Kit (S) PART #20479896 Max. 39- ~ Min. 22- inch Max. 19- ~ Min. 12- inch (# 20479861) (# 20474963) (# 20479861) (# 20474963) (# 20479853) (# 20479858) (# 20474950) (# 20474950) Pipe Support Hardware Pipe Support Hardware 40 inch...
Page 21: Safety Tips For Installation
SAFETY TIPS FOR INSTALLATION Follow the safety tips below when planning the installation of your Oil Miser 23. Intake and exhaust flue pipe openings must be fully exposed to outside air. Do not vent into chimney, garage, basement under the floor, or into any enclosed area.
Page 22: Installation Of Heater And Flue Pipe
INSTALLATION OF HEATER AND FLUE PIPE IMPORTANT: Check and comply with all state and local codes that may apply to vented heaters before beginning installation. NOTE: This heater is designed to be used at altitudes up to 3,000 FT. above sea level. For use at altitudes higher than 3,000 FT.
Page 23 For standard installation, use the template enclosed with the heater to position the hole for the flue pipe. Tack or tape template to the wall at the desired position (See Fig. 4) Type Fig. 4 NOTE: Heater should be installed on a sturdy floor that is level and flat. NOTE: The template can be adjusted for use of non-standard installations such as the use of extension pipe kits.
Page 24 Install the inner flue pipe. For wall thickness 5- ” to 9” From inside the room, insert the inner flue pipe through the hole. Make sure the arrow on the inner flue pipe is pointing up. Secure the inner flue pipe to the wall with the three wood screws. (See Fig.
Page 25 Insert the bent joint to the exhaust opening of the standard flue pipe. Cut the inlet hose for desired length if necessary. Attach the L-shaped hose to each end of the inlet hose and attach the L-shaped hose to the intake opening of the standard flue pipe. Secure the L-shaped hose to the intake opening with the hose band.
Page 26 Secure the L-shaped hose to the intake inlet opening with the hose band. Secure the bent joint to the standard flue pipe with the pipe holder (If the extension pipe is used, also attach the pipe holder to the connection of the bent joint and the extension pipe). Secure the bent joint (or the extension pipe) to the exhaust outlet opening by sliding the pipe stopper into the exhaust opening bracket (See Fig.
Page 27 A room temperature sensor is provided with approximately 8 feet long extension wire. It is located on the rear of the cabinet. Make sure that the extension wire is not touching the exhaust pipe. The room temperature sensor can be installed either with the self adhesive tape on the back or with a wood screw provided with the sensor depending on the type of surface chosen for installation.
Page 28: Permanent Wiring Installation
PERMANENT WIRING INSTALLATION WARNING: MAKE SURE POWER SUPPLY CORD IS DISCONNECTED TO AVOID ANY ELECTRIC SHOCK BEFORE SERVICING. ELECTRIC SHOCK MAY CAUSE SERIOUS INJURY. INSTALLATION SHOULD BE CONDUCTED BY A LICENSED ELECTRICIAN. Step 1. Step 4. Disconnect power supply cord Squeeze strain relief with the from power source.
Page 29: Section J
30. IMPORTANT: WHEN OPERATING THE Oil Miser 23 HEATER WITH NO.2 FUEL OIL. IT IS IMPORTANT TO USE A IN-LINE SMALL MESH SIZE FILTER. (e.g. 10 Micron Filter) LOCATED AS ILLUSTRATED ON PAGE 30.
Page 30 Oil Miser 23 Oil guide OIL GUIDE INSTALLATION When the fuel piping is installed, hook one fuel guide on the fuel pipe, then fit the other oil guide on the drip tray so that it pushes down from above.
Page 31: Limited Warranty
WHO IS COVERED : The original purchaser at retail. WHAT WE WILL DO : TOYOTOMI will either repair or replace, at its option, all defective parts free of charge that are covered by this limited warranty on a carry-in basis, to your nearest authorized dealer or distributor of TOYOTOMI.
