User Manual
User Manual
深圳开源通信有限公司
OpenVox-Best Cost Effective Asterisk Cards
OpenVox B200P B400P User Manual
Written by: James.zhu
Email:james.zhu@openvox.cn,zhulizhong@gmail.com
Date:15/09/2007
Version: 0.01
VoIPon
www.voipon.co.uk
sales@voipon.co.uk
Tel: +44 (0)1245 808195
Fax: +44 (0)1245 808299
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OpenVox B200P
Summary of Contents for OpenVox B200P
- Page 1 User Manual 深圳开源通信有限公司 OpenVox-Best Cost Effective Asterisk Cards OpenVox B200P B400P User Manual Written by: James.zhu Email:james.zhu@openvox.cn,zhulizhong@gmail.com Date:15/09/2007 Version: 0.01 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 2 No.9283,Binhe Road,Futian District,ShenZhen ,Guangdong 518048,China Tel:+86-755-82535095,82535461,Fax:+86-755-82535174 E-Mail：sales@openvox.com.cn IM for Sales: betty_yljiang@hotmail.com rubyzhang1217@hotmail.com IM for Technical Support: support@openvox.com.cn,zhulizhong@gmail.com,zhulizhongum@hotmail.com Business Hours: 9:30AM-17:30PM from Monday-Friday URL：www.openvox.com.cn Thank You for Choosing OpenVox Products! VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 3 User Manual Table of Contents Chapter 1 Overview………………………………………………………………… 4 Chapter 2 Card Installation and Configuration……………………………… 6 Chapter 3 Hardware Setting ……………………………………………………… 11 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 4: Chapter 1 Overview
Chapter 1 Overview 1. What is B200P/B400P B200P/B400P series is a PCI 2.2 compliant card supporting 2/4 BRI S/T interfaces, with an onboard multi NT power feeding circuit. NT/TE mode can be independently configured on each of the 2 or 4 ports. - Page 5 User Manual Figure 1: Asterisk Setup Source (http://www.siriusit.co.uk/uploads/images/consulting/asteriskSetup.gif) Asterisk provides Voicemail services with Directory, Call Conferencing, Interactive Voice Response, Call Queuing. It has support for three-way calling, caller ID services, ADSI, IAX, SIP, H.323 (as both client and gateway), MGCP (call manager only) and SCCP/Skinny(voip-info.org).
- Page 6 Setting Card ID Switch If user wants to install more than one cards of B200P or B400P in one pc, you should take care of the card id switch. It has three rules, which user must follow: 1.
- Page 7 These are for future usages. 2) Power off PC, remembering unplug the AC power cable 3) Insert B200P or B400P into a 3.3v or 5.0v PCI slot 4) Plug the hard disk power supply cable( D style) to power feeding input jack...
- Page 8 >.tar.gz /usr/src cd /usr/src/ version tar -xvzf bristuff-< >.tar.gz B. Download OpenVox patch called qozap.c from www.openvox.com.cn. It contains a patched qozap.c file, overwrite the orginal qozap.c file with the new qozap.c under /usr/src/bristuff-<version>/qozap. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195...
- Page 9 User Manual C. Make links with kernel source: ln -s /usr/src/kernels/2.6.18-8.el5-i686/ /usr/src/linux-2.6 Here, under /usr/src there is kernel source, user must create link linux-2.6 under /usr/src/. There many files under /usr/src/bristuff-0.3.0-PRE-1y-j, please check: D. Compiling Bristuff cd /usr/src/usr/src/bristuff-0.3.0-PRE-1y-j chmod 777 install.sh ./install.sh Above steps will install zaptel, libpri and asterisk.
- Page 10 F. If user wants to modify the call rules, edit zapata.conf file under /etc/asterisk to make sure asterisk run successfully asterisk –vvvvvvvvvvgc Notes: Test environments: OS: Centos 5 Kernel version: 2.6.18-8.15 Bristuff version: bristuff-0.3.0-PRE-1y-j Hardware：OpenVox B400P VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 11 User Manual Chapter 3 Hardware Setting VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
- Page 12 OpenVox B400P Jumper...
