1.2

Product Specifications

1.2.1

General

CPU: Embedded Intel Celeron M 1.0 GHz /Celeron M 600 MHz processor
System Chipset: Intel 855GME/852GM (bundle with Celeron 600MHz)
Power Management: APM1.2
SSD: Supports CompactFlash® Card TYPE I (shared 1st IDE Channel) (inter-
nal)
Expansion Interface: Supports 1 x PCI bus for standard PCI-104 device (inter-
nal)
Battery: Lithium 3 V/196 mA
I/O Interface:
– Front panel: COM1~2 for RS-232, 1 x KB/MS, 1 x VGA and 1 x USB3~6 2.0
– Rear Panel: 1 x Power LED,1 x LAN LED, 1 x LAN, 2 x USB 2.0, 1 x
DC_input, 1 x on/off switch, 1 x line-in, 1 x line-out, 1 x parallel port
LAN: Intel 82562EM,1 x 10/100 Base-T RJ45 Port
VGA/Keyboard/Mouse: 1 x DB-15 VGA connector, PS/2 keyboard & Mouse
Serial Ports: 2 x RS-232 with DB-9 connector
Standard: IEEE 802.3u 100Base-T
USB interface: Supports six USB 2.0; 2 x USB UHCI and 1 x DB-15-pin con-
nector for 4 x USB 2.0. ( need to use cable:1700005456 together)
Audio: Line in, Line out
LEDs: Power (Power on: Green); LAN (Connect: Green)
Print port: 1 x DB-25-pin connector
1.2.2

Display

Chipset: Intel 855GME/852GM integrated. (Extreme Graphics 2)
Memory Size: Optimized Shared Memory Architecture, supports up to 64 MB
frame buffer using system memory
Resolution:
– CRT Display mode: Pixel resolution up to 1600 x 1200 at 85-Hz and 2048 x
1536 at 75-Hz
– LCD Display mode: Dual channel LVDS panel supports up to UXGA panel
resolution with frequency range from 25 MHz to 112 MHz (optional connec-
tor, internal pin header)
LVDS: Two Hirose connectors support up to 2 channel LVDS LCD Panel (inter-
nal pin header)
Note! If you need to pull out the internal pin header/connector, or need to mod-
ify an enclosure connector; please ask the regional support team for the
modification process.
3 ARK-4180 User Manual
