Summary of Contents for British Fires Berkshire L30G
- Page 1 British Fires Berkshire MODEL : L30G All instructions must be handed to user for safekeeping Revision A - 08/06 Country(s) of destination - GB/IE INSTALLATION AND USER INSTRUCTIONS...
- Page 2 Berkshire...
-
Page 3: Installation Instructions
Accordingly, the room should be well ventilated with all windows and doors open during this period. Read all these instructions before commencing installation. Manufactured by : British Fires, Reid Street Christchurch, Dorset BH23 2BT Tel: 01202 588 617 www.britishfires.com... -
Page 4: Table Of Contents
Section Contents Page No. Section Contents Page No. Important Notes Testing and Commisioning Appliance Data Operating the Appliance Installation Requirements Spark Failure 3.1 Room Sizing Setting pressure Site Requirements Fitting the Decorative Frame 4.1 Ventilation Fitting the Side Panels Unpacking the Appliance Briefing the customer 5.1 Component Checklist 10.0... -
Page 5: Appliance Data
APPLIANCE DATA Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20 mbar Max Energy Input Gross 2.6 kW 2.35 kW Max Gas Rate 0.25 m3/h Min Energy Input Gross 1.5 kW 1.35 kW Pilot Energy Input Gross 166 W 150 W Burner Pressure High... -
Page 6: Ventilation
SITE REQUIREMENTS (continued) Clearances to non-combustibles Non combustible surfaces are defined as brick, metal, marble, concrete etc. and also a number of man- made materials impervious to flame. If in doubt refer to the material manufacturer for further information before proceeding with installation. Clearances to the sides of the appliance are 100mm (4in). -
Page 7: Unpacking The Appliance
VENTILATION (continued) Any ventilation fitted must comply with BS 5871 part 2 and BS 5440 part 2. Ventilation fitted under, or within immediate vicinity of the appliance must not be used as it may adversely effect performance of the ODS system. The appliance MUST NOT be installed in a bedroom, bathroom or any sleeping area. For Republic of Ireland, see relevant rules in force. -
Page 8: Fixing The Appliance
FIXING THE APPLIANCE After having selected the final mounting position of the appliance, taking into account the site requirements as speci- fied in section 4 of these instructions, the integrity of the wall, and the feasibil- GAS MODEL L30G ity of the proposed supply pipe routing, the firebox of appliance may be secured to the wall. -
Page 9: Testing And Commisioning
TESTING AND COMMISSIONING Turn on and test the gas supply up to the fire for any leaks, in accordance with the current edition of BS6891. OPERATING THE APPLIANCE The pilot is visible behind the left hand side of the burner. ‘OFF’... -
Page 10: Fitting The Decorative Frame
FITTING THE DECORATIVE FRAME ASSEMBLY Remove the decorative frame assembly from any protective ‘Berkshire’ frame assembly packaging, and remove any protective film that may be present on the frame. The frame assembly is support- ed by four M6 screws which protrude from the front of the outer casing. -
Page 11: Briefing The Customer
BRIEFING THE CUSTOMER All instructions must be handed to the user for safekeeping. Show the customer how to light and control the fire. After commissioning the appliance, the customer should be instructed on the safe use of the appli- ance and the need for regular servicing. Frequency of service depends on usage, but MUST be carried out at least once annually. -
Page 12: Pilot Assembly
10.2 PILOT ASSEMBLY Clean the pilot assembly with a soft brush and blow through. Check the aeration holes are free of any dirt or lint. Clean thoroughly internally, the connection can be removed from the base of the pilot unit using two spanners to make cleaning easier. -
Page 13: Troubleshooting Guide
11.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipe work blockage, clean out. Air not fully purged, re purge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. -
Page 14: User Instructions
USER INSTRUCTIONS Section Content Page No Important Notes Clearances to Combustibles Ventilation & Room Size Operating Instructions Combustion Monitoring System Cleaning Servicing List of Replacement Parts IMPORTANT NOTES The installation and Servicing of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the rel- evant British Standards, Codes of Practice, the Building Regulations and the manufacturer's instructions. -
Page 15: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES Clearances to combustible materials Combustible materials are defined as wood, fabrics, or other materials likely to combust if exposed to flame. Generally, any material, which is likely to discolour, melt or misshape when exposed to moderate heat, should be considered as a combustible material or surface. Clearance to the sides of the appliance are 100mm(4in) but curtains, drapes and other fabrics are not per- mitted within a distance of 500mm(20in) of the appliance sides. -
Page 16: Operating Instructions
VENTILATION AND ROOM SIZE (continued) The room size should be a minimum of 30m 3 (e.g. 11’6” x 11’6” x 8’) to allow adequate circulation of air and ensure the correct operation of the fire. This volume may include adjacent spaces but these spaces must not be separated by a door.
