4.2 Main Function
To select any of the given functions, press the MENU button up to when the required
one is showing on the display. Select the function by ENTER button and the display will blink.
Use DOWN and UP button to change the mode. Once the required mode has been selected,
press the ENTER button to setup or it will automatically return to the main functions without
any change after idling 8 seconds. To go back to the functions without any change press the
MENU button. The main functions are showing below:
DMX512 Address Setting
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to change the DMX512 address.
Once the address has been selected, press the ENTER button to setup or automatically
return to the main functions without any change after 8 seconds. To go back to the functions
without any change press the MENU button again.
is showing on the display. Pressing ENTER
Show Mode
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
or (show 2) or
been selected, press the ENTER button to setup or automatically return to the main
functions without any change after 8 seconds. To go back to the functions without any
change press the MENU button again.
Show 1 mode - Fixture is placed on the floor. Tilt movement angle 210°.
Show 2 mode - Fixture is fixed under ceiling. Tilt movement angle 90°.
Show 3 mode - Fixture is placed on the speaker, The spot is always projecting
to the audience's direction; i.e in front of the stage. Pan movement angel ( left to
right to left ): 160°. Tilt movement angel: 90° ( 60° above horizon; 30° below
horizon.)
Show 4 mode - Fixture is fixed under ceiling. The spot is mainly projecting in
front of the stage. Pan movement angel ( left to right to left ) :160°. Tilt
movement angel: 90° ( vertically, front 75°; back 15° )
10A
Slave Mode
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(normal) or (2 light show) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
Blackout Mode
Press the MENU button up to when the
ENTER button and the display will blink. Use DOWN and UP button to select the
(yes blackout) or (no blackout) mode. Once the mode has been selected, press the
ENTER button to setup or automatically return to the main functions without any change
after 8 seconds. To go back to the functions without any change press the MENU button
again.
is showing on the display. Pressing ENTER
(show 3) or (show 4) mode. Once the mode has
is showing on the display. Pressing
is showing on the display. Pressing
(show 1)
