- Page 1 Installation, Operating, Maintenance and After Sales Manual. SLIM-LINE RC heatingthroughinnovation. Product Serial Number: Please leave this manual with the end user. Part Number: 1371057 Tested to UL & CSA Standards Issue 1...
-
Page 2: Table Of Contents
Contents General Information Heating System Design Unit Selection/Sizing Location Preparation Fixing Water Connections Electrical Connection Commissioning Procedure 10.0 Technical Data 11.0 Operating Instructions 12.0 Troubleshooting 13.0 Maintenance... -
Page 3: General Information
In G The SLIM-LINE RC can be used on heat pump systems, for manual mode any of the 3 available fan speeds can be heating only. -
Page 4: Preparation
SLIM-LINE RC 5.0 Preparation Before proceeding with the installation, unpack the carton contents and check against the checklist below: 1. SLIM-LINE RC unit. " isolating valves (1 pair). 3. Instruction manual. 4. Fixing kit (rubber mounts and cable gland). 5. Remote control handset. -
Page 5: Water Connections
G Ensure system is flushed in accordance with recognised best practice and a suitable inhibitor is added to the system as Note: For SLIM-LINE RC installations pipe-work must not be necessary. routed directly underneath the unit as this will adversely affect G Open valves fully, check pipe connections for leaks and vent the operation of the integral room thermostat. -
Page 6: Electrical Connection
SLIM-LINE RC 8.0 Electrical Connection WARNING: This appliance must be grounded. The electrical installation must comply with state and local codes. G Electrical cable entry to the unit should be made at the bottom left hand side of the unit. -
Page 7: Commissioning Procedure
SLIM-LINE RC 9.0 Commissioning Procedure G Fill and vent the system. G Refit cover. G Open both valves fully and vent air from the heat exchanger G Switch on electrical supply. by unscrewing the air bleed valve situated above the valves in the angled top of the chassis. -
Page 8: Technical Data
SLIM-LINE RC 10.0 Technical Data Heating Performance Data Heat Output (Btu/h) Flowrate Flowrate Entering Water Temperature (°F), entering air temperature 65°F Setting Boost 5029 5663 6657 7661 8664 9668 10572 11678 12680 13864 Medium 4385 4881 5887 6745 7651 8559... -
Page 9: Operating Instructions
This means This SLIM-LINE RC unit is fitted with a control system that that air circulation can be provided in summer for example, or provides either automatic or manual control of the unit. -
Page 10: Troubleshooting
An apparent problem with this unit may be the result of system controls being incorrectly set and can be solved easily without calling out your installer or MYSON. Before calling your installer or MYSON, please carry out the checks listed opposite. -
Page 11: Maintenance
If the fan convector is still faulty after checking the above, call your installer or MYSON. Common Installation Faults heat, and the heating system must be correctly designed to provide adequate flow of hot water to the unit (see Section 2). - Page 12 802 654 7500, 802 654 7022, info@mysoninc.com, www.mysoninc.com heatingthroughinnovation. After Sales Service: MYSON Service, Somerden Road, Hull, East Yorkshire HU9 5PE T: 01482 713927, F: 01482 789056, service.convectors@myson.co.uk Spare parts and technical help on all Convector products are available from MYSON Service.
