Anchor Fiesta Installation Instructions

Marquee stair step kit

Hide thumbs Also See for Fiesta:

Installation Instructions

Fiesta

Marquee Stair Step Kit

UPPER LEVEL

DESCENDING ANGLE

INCLINED SECTION

LOWER LEVEL

ASCENDING ANGLE

Please read all assembly / installation instructions before the installation or removal of this product.

7701 Highway 41 N

Evansville, IN 47725

Phone: 812-867-2421

Fax: 812-867-1429

1-800-544-4445

email: tents@anchorinc.com

www.anchorinc.com

EC5608

Rev 220

Table of Contents

Need help?

Do you have a question about the Fiesta and is the answer not in the manual?

Page 1 Installation Instructions Fiesta Marquee Stair Step Kit ® UPPER LEVEL DESCENDING ANGLE INCLINED SECTION LOWER LEVEL ASCENDING ANGLE Please read all assembly / installation instructions before the installation or removal of this product. 7701 Highway 41 N Evansville, IN 47725...
Page 2 Adjustable Elbow (1) 3. Note: The alignment hole rotation depends upon the location of the part in the Fiesta Marquee frame. The adapters located at the ridge line of the Marquee will have the alignment holes facing upward in a 90 degree vertical direction. Those adapters located at the eave line will have the alignment hole rotated 45 degrees to the outside of vertical (left or right, depending upon which side of the Marquee the part will be.
Page 3 Adjustable Elbows, using a 5/16” Allen Wrench (see Fig.9). Inserts 10. Insert and pin standard Fiesta Marquee rafters from eave to peak to eave to complete the angle. Adapter Splices aligned for up and down vertical swings.
Page 4 WARNING...
