SERIAL # ____________________ MFG. DATE _____________ PURCHASE DATE: ____________
This instruction manual contains important information necessary for the proper
•
assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the
•
appliance.
Keep this manual for future reference.
•
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at U.S.: 800-913-8999, 8 a.m.-5 p.m., PST, Monday-Friday.
OUTDOOR GAS GRILL
MODEL #720/730-0778E Pages 2 - 33
PARRILLA DE GAS PARA
MODELO #720/730-0778E Páginas 34 - 65
EXTERIORES
19000393A0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0778E and is the answer not in the manual?

Questions and answers

Related Manuals for Nexgrill 720-0778E

Summary of Contents for Nexgrill 720-0778E

  • Page 1 OUTDOOR GAS GRILL MODEL #720/730-0778E Pages 2 - 33 PARRILLA DE GAS PARA EXTERIORES MODELO #720/730-0778E Páginas 34 - 65 SERIAL # ____________________ MFG. DATE _____________ PURCHASE DATE: ____________ This instruction manual contains important information necessary for the proper • assembly and safe use of the appliance.

  • Page 2: Table Of Contents

    • El presente manual de instrucciones contiene información importante que lo ayudará a armar el dispositivo correctamente y a utilizarlo de manera segura. • Ce manuel d’instructions contient d’importantes informations essentielles à un assemblage approprié et sécuritaire de l’appareil. • Antes de armar y utilizar el dispositivo, lea y siga todas las advertencias e instrucciones.

  • Page 3: Safety Instruction

    Safety Instruction DANGER WARNING If you smell gas: Do not store or use gasoline or Shut off gas to the appliance. other flammable liquids or vapors in Extinguish any open flame. the vicinity of this or any other Open lid. appliance.
  • Page 4 Safety Instruction WARNING ELECTRICAL GROUNDING INSTRUCTIONS Rotisserie Motor-This appliance is equipped with a plug and should be plugged directly into a properly grounded receptacle. When installed, must be electrically grounded in accordance with local codes or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22.1 DO NOT cut or remove the grounding prong from this plug.
  • Page 5 Safety Instruction continued LP-Gas Supply System • The gas must be turned off at the supply cylinder when the outdoor cooking gas appliance is not in use. • LP gas tank must be stored outdoors in a well-ventilated area and out of reach of children. Disconnected LP gas tanks must not be stored in a building, garage or any other enclosed area.
  • Page 6 Safety Instruction continued INSECT WARNING Use a covered hand when opening the grill lid. Spiders and insects can nest in the burners of this and any Never lean over an open grill. other grill, and cause the gas to flow improperly. This is a very dangerous condition, which can cause a fire to occur When lighting a burner, pay close attention to what you are behind and beneath the valve panel, thereby damaging the...

  • Page 7: Package Content List

    Package Content List Firebox Assembly --------1pc. B. Bottom Panel--------------1pc. C. Door----------------------2pcs. D. Side Burner Shelf----------1pc. E. Tank Heat Shield-----1pc. F. Left Side Shelf----------1pc. G. Left Side Panel-------------1pc. H. Right Side Panel-----------1pc. I. Back Panel----------------1pc. J. Swivel Caster --------------1pc. K. Swivel Caster with Brake-1pc. L.

  • Page 8: Hardware Contents

    Package Content List V. Main Grease Tray----1pc. W. Control Knob----------------- 1pc. X. Side Burner Cooking Grid ------1 pc. Y. Bottle Opener------------1pc. Z. Battery ---------5pcs. A1.Grease Box ----1pc. Hardware Contents Note: Below table of hardware are KD assembly but hardware in step 6, 8, 10 of instruction are pre- assembly.

  • Page 9: Exploded View

    Explode View...

  • Page 10: Part List

    Part List Warranty Warranty Part (Description) coverage Part (Description) coverage (Year) (Year) Main lid Hook Main lid screw Warming rack Temperature gauge Cooking grid Logo Flame tamer Hood buffer C R shape pin Main burner bowel Non- Main burner igniter wire A assembly replaceable Flange, left...

  • Page 11: Part List

    Part List Warranty Warranty Part (Description) coverage Part (Description) coverage (Year) ( Year ) Triangle bracket for side Swivel caster with brake shelf Triangle bracket for side Side panel, Left burner Bottom panel Side burner flex gas line B Side burner orifice brass Swivel caster connector sold...

  • Page 12: Assembly Instruction

    Assembly Instructions 1. Caster Assembly Fig. 1 Mount the casters onto the bottom panel (B) using sixteen 1/4-in. x 15-mm truss head screws with locking washers (CC). The swivel caster with brake (K) should be positioned under the Left rear of the cart bottom and the swivel caster (J) should be positioned under Left front as shown in Fig.

  • Page 13: Assembly Instructions

    Assembly Instructions Fig. 4 4. Back Panel Assembly Remove the back panel from the carton. Position the back panel (I) with the flat side facing outward. Attach the back panel to the bottom panel (B) with three 1/4- in. x 15 mm truss head screws with locking washers (CC) as shown in Fig.
  • Page 14 Assembly Instructions Fig. 7 Attach the firebox assembly (A) to the grill cart using four 1/4-in. x 15 mm truss head screws with locking washers (CC) Tighten the battery box with three screws pre- assembled on the Left Side Panel. Note: Two screws with two washers for each side of cart as shown in Fig.
  • Page 15 Assembly Instructions Fig. 10 Attach the two door hinges to the flange using twelve 5/32-in. x 10 mm flat head screws (EE) as shown in Fig. 10. HINT: Six screws for each door Fig.11 8. Right Side Burner Shelf Assembly 8a) Loosen the 2 screws which are pre- assembled onto the firebox right panel, but do not remove completely, as shown in Fig.11.
  • Page 16 Assembly Instructions Fig.14 8c) Align the bottom key holes on side burner shelf (D) with 2 loosened screws on right side panel. Attach the side burner bowel to the cart with the two loosened screws on the side panel as shown in Fig.14 Tip: This step is meant to help with the installation but does not depend solely on the two screws to hold the weight of the side burner shelf.
  • Page 17 Assembly Instructions Fig.16 10. Side Burner Valve Installation Slide the bezel opening over the valve stem and attach the side burner valve assembly and bezel to the side burner shelf with the screws removed as shown in Fig.16 Valve Bezel Fig.17 Attach side burner orifice bracket with side burner tube with preassembled brass screw then tighten by...
  • Page 18 Assembly Instructions Fig.19 12.Igniter Wire Installation Insert the side burner ignition wire to the ignite module as shown in Fig.19 Note: You only need to insert the side burner ignition SB igniter wire wire, the other five wires have been pre-assembled. Reminder: While completing igniter wire installation, make sure there is a 3 mm gap between the igniter pin and the side...
  • Page 19 Assembly Instructions Fig.22 15. Flame Tamers, Cooking Grids Installation Place the flame tamers (N), main cooking grids (M), side burner cooking grid (X) and warming rack (T) into the grill as shown in Fig. 22 16. Liquid Propane Tank Installation Fig 23 Place the liquid propane tank into the hole Place the liquid propane tank into the hole...

  • Page 20: Gas Hook Up

    Gas Hook - Up NEVER CONNECT AN UNREGULATED GAS SUPPLY LINE TO THE APPLIANCE. USE THE REGULATOR/HOSE ASSEMBLY SUPPLIED. This is a liquid propane configured grill. Do not attempt to use a natural gas supply unless the grill has been reconfigured for natural gas use.

  • Page 21: Installer Final Check List

    Installer Final Check List Minimum clearance from sides and back of unit USER, PLEASE RETAIN THIS MANUAL FOR to combustible construction, 24 inches (61 cm) FUTURE REFERENCE. from sides and 24 inches (61 cm) from back PROPANE CYLINDER CAUTIONS All internal packaging removed. a) Do Not store a spare LP-gas cylinder under or Knobs turn freely.

  • Page 22: Leak Testing

    Leak Testing continued CAUTIONS Place dust cap on cylinder valve outlet when the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.

  • Page 23: Operating Instruction

    Operating Instructions GENERAL USE OF THE GRILL AND ROTISSERIE NOTE: The hot grill sears the food, sealing in the juices. The more thoroughly the grill is preheated, the faster Each main burner is rated at 12,000 Btu/hr. The main the meat browns and the darker the grill marks. grill burners encompass the entire cooking area and DO NOT LEAVE THE GRILL UNATTENDED WHILE are side ported to minimize blockage from falling...

  • Page 24: Lighting Instruction

    Grill Lighting Instructions continued TO MATCH LIGHT THE SIDE BURNER Hold a lit extended match near the side burner ports, turn the control knob counter clock wise to “IGNITE/HI.” Move your hand immediately once the burner is lit. Rotate the control knob to the desired setting.
  • Page 25 Lighting Instructions continued Make sure the lid is open. Push and slowly turn the Rear Burner knob to IGNITE/ON position. Keep knob pressed in until the burner is lit. Once IGNITE / ON it is lit, continue to press and hold for another 15 seconds to ensure the burner stays lit.

  • Page 26: Care And Maintenance

    Care and Maintenance STAINLESS STEEL Warning: If you wish to replace main burner, we There are many different stainless steel cleaners available. strongly recommend that you hire a Always use the mildest cleaning procedure first, scrubbing in professionally trained technician to replace it. the direction of the grain.

  • Page 27: Trouble Shooting

    Trouble Shooting SPIDER AND INSECT WARNING Checking and cleaning burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire beneath the grill. Spiders and small insects occasionally spin webs or make nests in the grill burner tubes during transit and warehousing. These webs can lead to gas flow obstruction which could result in a fire in and around burner tubes.
  • Page 28 Trouble Shooting continued PROBLEM SOLUTION When attempting to light my grill, it will Make sure you have a spark while you are trying to light the burner (if no spark). not light immediately. Ensure that the wire is connected to the electrode assembly. Clean wire (s) and/or electrode with rubbing alcohol and a clean swab.

  • Page 29: Ordering Parts

    Ordering Parts HOW TO ORDER REPLACEMENT PARTS IMPORTANT To make sure you obtain the correct replacement part (s) Use only factory authorized parts. The use of any part for your gas grill, please refer to the parts list on pages that is not factory authorized can be dangerous.
  • Page 30 Grill Cooking Chart continued WEIGHT OR HEAT APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS SETTING TIME AND TIPS Place in aluminum foil pan. French fries Medium 15 to 30 minutes Grill, stirring occasionally Grill, turning once when juices rise to the MEATS AND 1/2 to 3/4 inch surfaces.

  • Page 31: Grill Recipe Suggestion

    Grill Recipe Suggestion BBQ SALMON butter and sprinkled with chopped Combine first 4 ingredients, add onion parsley and a crisp lettuce salad. and marinade flank steak with it. 2 large salmon steaks In medium bowl, combine shrimp and Refrigerate at least 4 hours or 2 tbs.(30mL) oil scallops.
  • Page 32 Grill Recipe Suggestion continued FAJITAS Bring marinade to boil on the side Marinade ribs for 3 hours. Use 1-1/2 lb. flank steak or boned chicken burner in a saucepan. Add remaining marinade for basting by adding beer breasts 1/3 c. water and peanut butter. Stir to to it.

  • Page 33: Limited Warranty

    You may also have other rights which vary from province to province. If you wish to obtain performance of any obligation under this limited warranty, you should write to: Nexgrill Customer Relations 5270 Edison Avenue, Chino, CA 91710 All consumer returns, parts orders, general questions, and troubleshooting assistance can be acquired by calling U.S: 800-913-8999...
