ASSEMBLY & OPERATING INSTRUCTIONS
Liquid Propane Gas Grill
!
WARNING:
Read this Owner's manual carefully and be
sure your gas grill is properly assembled,
installed and maintained. Failure to follow these
instructions could result in serious injury and/or
property damage. This gas grill is intended for
outdoor use only and is not intended to be
installed in or on recreational vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer
after delivery and/or installation.
Note to Consumer
Leave this Owner's Manual in a convenient
place for future reference.
Customer Service Helpline:
For parts ordering, call:
1-800-913-8999
MFG No.: 720-0719BL
Please make sure the cylinder valve
connection device shall properly and safely
mate with the connection device attached to
the inlet of the pressure regulator.
Nexgrill Industries, INC.
5270 Edison Ave. Chino, CA 91710
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting
Advertisement
Table of Contents
Related Manuals for Nexgrill 720-0719BL
Summary of Contents for Nexgrill 720-0719BL
- Page 1 For parts ordering, call: outdoor use only and is not intended to be 1-800-913-8999 installed in or on recreational vehicles or boats. MFG No.: 720-0719BL Note to Installer Leave this Owner’s Manual with the customer Please make sure the cylinder valve after delivery and/or installation.
-
Page 2: Table Of Contents
Do not store or use gasoline or Nexgrill Grill Warranty other flammable liquids or One-Year Full Warranty on Nexgrill Grill vapors in the vicinity of this or If this grill fails due to a defecting material or any other appliance. -
Page 3: Safety Precautions
Precautions A tank of approximately 12 inches in diameter by 18- • Have your LP gas tank filled by a reputable 1/2 inches high is the maximum size LP gas tank to propane gas dealer and visually inspected and re- use. - Page 4 Burner Flame Check WARNING A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
-
Page 5: Packaging Content List
PACKAGE CONTENTS LIST A. Firebox--------1 pc. B. Cart Leg, Front Left------1 pc. C. Cart Leg, Rear Left----1 pc. D, Cart Leg Foot-----2 pcs. E. Side Panel, Left----1 pc. F. Cart Brace, Left------1 pc. G. Cart Leg, Front Right-----1 pc. H. Cart Leg, Rear Right-----1 pc. I. - Page 6 S. Cart Frame, Rear------1 pc. T. Side Burner bowl assembly U. Left side shelf with side shelf frame with Side burner control front panel---------1 pc. panel-----1 pc. V. Bezel---------------------------1 pc. W.. Control Knob--------------1 pc. X.. 1.5 Volt “AA” Size Alkaline Battery----------1 pc.
-
Page 7: Hardware Pack
Hardware Pack Contents Required for assembly Pack Description (pcs) 5/32-in. x 8-mm Round Head Screw 5/32-in. Lock Washer 1/4-in. x 10-mm Round Head Screw 1/4-in. Lock Washer Allen Key 1/4-in. x 65-mm Round Head Screw 1/4-in. Flat Washer Preparation Before beginning assembly, make sure all parts are present. Compare parts with package contents list and diagram above. -
Page 8: Assembly Instructions
Assembly Instructions UNPACKING Fig. 1 CAUTION: Obtain the aid of an assistant when handling large or heavy grill components. 1. Remove all packing material from around grill exterior. 2. Open Firebox lid and remove packing materials and components from inside Firebox. 3. - Page 9 2. Wheel Assembly Fig. 5 Remove Axle Bushing (R) and Screws from the ends of Wheel Axle (K). Insert Wheel Axle (K) through Cart Leg, Front Right (G) and Cart Leg, Back Right (H). Place Axle Bushing and Wheel (L), cone side facing Leg, on each end of Axle.
- Page 10 5. Front Panel Assembly Fig. 9 (a) Use 2 AA Round Head Screw and 2 BB Lock Washer to attach hadle to Front Panel B (P) (Fig (b) Use 4 AA Round Head Screws and 4 BB Lock Washer to attach the Front panel A (O), to the Front Left Cart Leg (B ) and Front Right Cart Leg (G),see (Fig.
- Page 11 (b) Raise firebox lid and from inside the Firebox Fig.13 use 4 CC Round Head Screws to attach the sides of Firebox to Cart Brace, Left (F) and Cart Brace, Right (J). Raise Firebox slightly to align holes for inserting and tightening screws. See (Fig. 13). (c) From the inside of the cart, use 2 CC Round Head Scews and 2 DD lock washers, attch Rear Right Cart Leg (H) and Rear Left Cart Leg (C) to...
- Page 12 (b) Remove two screws from side burner control valve Fig. 18 face. Insert side burner valve control stem through hole in side burner control panel . Place side burner control knob bezel (V) over side burner valve control stem. Secure bezel to control panel and valve with 2 screws removed above.
- Page 13 10. Grease Cup Assembly Fig. 22 From the back, pull in grease tray (Y), remove any packaging materials from it, then insert grease cup (Z) into grease tray (Y) as shown in (Fig.22). Push grease tray back into grill. 11. Installing Cooking Components (a) Place flame tamer (ZA) over burners as shown.
- Page 14 Important DISCONNECTING THE LIQUID PROPANE Before cooking on your grill the first time, wash CYLINDER cooking grids and cooking rack with warm , Turn the grill burner valves “OFF” and make sure the soapy water. Rinse and dry thoroughly. Season grill is cool.
-
Page 15: Lighting Instructions
3. Be sure all gas connections are securely Checking for LP gas leaks tightened. 4. Turn on gas supply. Never test for leaks with a flame. Prior to first use, at 5. Open the grill main lid. the beginning of each season, or every time your LP 6. - Page 16 WARNING If Grill Still Fails To Light Never lean over the grill cooking area while 1. Check gas supply and connections for leaks. Check lighting your gas grill. Keep your face and body that all wire connections are secure. a safe distance (at least 18 inches) from the cooking grid surface when lighting your grill by 2.
-
Page 17: Cleaning And Maintenance
Cleaning Exterior Stainless Steel Surfaces Cleaning and Maintenance Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Machine oils used in manufacturing process of stainless steel can also To ensure a proper working unit the following proper cause this tanning color. -
Page 18: Troubleshooting
WARNING 2. Clean any clogged ports with a stiff wire, such as The location of the burner tube with respect to the an open paper clip. orifice is vital for safe operation. Check to ensure the 3. Inspect each burner for damage (cracks or holes) orifice is inside the burner tube before using the gas and if such damage is found, order and install a new grill. -
Page 19: Cooking Instructions
Cooking Instructions Indirect Cooking To cook indirectly, the food should be placed on the left or right side of your grill with the burner lit WARNING on the opposite side. Do not leave the grill unattended. Your grill will get very hot. Never lean over Flare-ups the cooking area while using your grill. -
Page 20: Cooking Chart
Cooking Chart FOOD Weight or thickness Temperature Time Special instructions and tips Slice or chop vegetables and dot with butter or Vegetables Medium 8 to 20 minutes margarine. Wrap tightly in heavy duty foil. Grill turning occassionally. Wrap individually in heavy duty foil. Cook Potatoes Whole Medium... -
Page 21: Parts Diagram
Model 720-0719BL Parts diagram... -
Page 22: Parts List
4. Part Description To make sure you obtain the correct replacement 5. Quantity of parts needed parts for your Nexgrill gas grill, please refer to the part numbers on this page. Important: Keep this Use & Care Guide for convenient...
