Page 1
(página 25-49) GRIL AU GAZ DE PÉTROLE LIQUÉFIÉ (page 50-74) MODEL / MODELO / MODÈLE # 720-0783A WARNING WARNING To reduce the risk of fire, burn hazard or other injury, This grill is not intended to be installed in or on read the manual carefully and completely before recreational vehicles and/or boats.
Table of Contents Precautions WARNING Failure to comply with these instructions could Warranty----------------------------------------------- result in a fire or explosion that could cause Precautions------------------------------------------- serious bodily injury, death, or property damage. Package Contents List------------------------------ Hardware Contents---------------------------------- Parts Diagram --------------------------------------- Parts List----------------------------------------------- WARNING Preparation-------------------------------------------- Your grill will get very hot.
Precautions A tank of approximately 12 inches in diameter by 18-1/2 Have your LP gas tank filled by a reputable inches high is the maximum size LP gas tank to use. propane gas dealer and visually inspected and re- qualified at each filling. You must use an OPD gas tank which offers an Do not store a spare LP gas tank under or near Overfill Prevention Device.
Page 4
WARNING Burner Flame Check A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
Package Contents List A. Firebox --- 1pc. B. Bottom Panel --- 1pc. C. Caster --- 2pcs. D. Swivel Caster with Brake --- 1pc. E. Swivel Caster --- 1pc. F. Door handle seat--- 4pc G. Side Panel, Left --- 1pc. H. Side Panel, Right --- 1pc. I.
Page 6
T. Side Burner Cooking Grid, Right U. Control Knob --- 2pcs. V. AA Size Alkaline ---1pc. --- 1pcs. W. Grease Pan --- 1pc. X. Grease Cup --- 1pc. Y. Manual Lighting Stick --- 1pc. Z. Cart Frame --- 1pc. A1. Sear Burner Cooking Grate B1.
Parts List Warranty Warranty PART (Description) coverage PART (Description) coverage (Year) (Year) Main Lid Side Shelf Control Panel, Right Main Lid Screw Side Burner Pipe Burner Pin Assembly Side Burner Igniter Wire Temperature Gauge Sear Burner Lid Temperature Gauge Housing Sear Burner Lid Hinge Rod, Left Logo Sear Burner...
If you are missing hardware or have damaged parts Important: Use only parts listed above. When ordering after unpacking grill, call 1-800-648-5864 parts, providing the following information: for replacements. • Model # To order replacement parts after using grill, call: •...
Page 11
Fig.4 (d) Attach Triangle Bracket Left (D1) and Triangle Bracket right (E1) to both side panels (G & H) using (8) Truss head screws (BB) with (8) Lock washers. See Fig.4. (e) Attach the diagonal bar barrier to back & bottom panel using (2) Truss Head Screws (BB) with (2) lock washers.
Page 12
(g) Attached door handle (K) to door handle seat (F), Fig.7 See Fig.7. (h) Attach door handle to left door (L) using (2) Truss head screws (FF). Repeat to assemble the other door handle to right door (M). See Fig.8. Attach two doors (L &...
Page 13
Fig.11 Fig.10 Fig.12 Side Burner Assembly (a) Loosen (2) preinstalled head screws from right side of Firebox (A) as shown. Do not screw out fully; leave ¼ extended for shelf assembly. Through side burner shelf keyholes, hang side burner shelf (N) on two loosened screws. See Fig.
Page 14
Fig.13 5. Side Burner Valve Assembly (a) Insert the side burner valve into the Side Burner Shelf Control Panel (N). Align the screws on the valve with the large side of the holes on the bezel. Slightly loosen the screws without removing the screws.
Page 15
Fig.17 Searing Side Burner Assembly Loosen (2) preinstalled head screws from left side of Firebox (A) as shown. Do not screw out fully; leave ¼ extended for shelf assembly. Through side burner shelf keyholes, hang side burner shelf (O) on two loosened screws. See Fig.17.
Page 16
Fig.20.1 (c) Replace the searing side burner, angling it so that the side burner tube slides over the valve orifice. See Fig.20.1. (d) Locked 3 screws removed in step a. See Fig.20.2. (e) Loosen the "C" bracket on the burner tube located on the underside of the side shelf bowl by removing the screw holding it in place.
Page 17
8. Side Burner Grates Assembly Fig.22 Replace both grates to each side burner. See Fig.22. 9. Grease Cup Assembly From the back, pull out grease trays (W & J), remove any packaging materials from it, then insert grease cup (X) into grease tray (W) as shown in Fig.23. Push grease trays back into grill.
Page 18
Congratulations Your Nexgrill® gas grill is now ready for use. CAUTION: When the appliance is not in use, Before the first use and at the beginning of each gas must be turned off at the supply tank.
3. Be sure all gas connections are securely Checking for LP gas leaks tightened. 4. Turn on gas supply. Never test for leaks with a flame. Prior to first use, at 5. Open the grill main lid. the beginning of each season, or every time your LP 6.
Page 20
If Grill Still Fails To Light WARNING 1. Check gas supply and connections for leaks. Never lean over the grill cooking area while Check that all wire connections are secure. lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the 2.
Cleaning Exterior Stainless Steel Surfaces Cleaning and Maintenance Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Machine oils used in manufacturing process of stainless steel can also cause To ensure a proper working unit the following proper this tanning color.
2. Clean any clogged ports with a stiff wire, such as WARNING an open paper clip. The location of the burner tube with respect to the 3. Inspect each burner for damage (cracks or holes) orifice is vital for safe operation. Check to ensure the and if such damage is found, order and install a new orifice is inside the burner tube before using the gas burner.
Cooking Instructions WARNING WARNING Do not line the bottom of the grill housing with Do not leave the grill unattended. aluminum foil, sand or any substance that will Your grill will get very hot. Never lean over restrict the flow of grease into the grease tray. the cooking area while using your grill.
Grill Cooking Chart Warning: To ensure that it is safe to eat, food must be cooked to the minimum internal temperatures listed in the table below. Food Temperature Beef, veal and lamb (pieces and whole cuts) - medium-rare 63°C (145°F) Beef, veal and lamb (pieces and whole cuts) - medium 71°C (160°F) Beef, veal and lamb (pieces and whole cuts) - well done...
