Valor 534 Installation Instructions Manual

CSA approved for use with Valor Heaters Models 534 and 535 ONLY
WARNING
!
A barrier designed to reduce the risk of burns from the hot viewing
glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.
The 601SFB Standard Front in black or 601SVI
Standard Front in vintage iron are designed to be
used on their own or along with an outer surround trim
(supplied separately) on the 534 or 535 Valor Horizon
heaters.
The Standard Front fi ts within the heater's black frame
and clips onto the mounting brackets inside the frame.
It is compatible with the 603FSK, 604FSK, 605FSK and
606FSK Trim Kits.
34-7/8" (887 mm)
601SFB or 601SVI
4001167-03
© Copyright Miles Industries Ltd., 2013
H
ORIZON
601 Standard Front

Installation Instructions

HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Finished wall
(See appliance
installation manual)
3/4"
(19 mm)
Outer Trim
Supplied
Separately
I NSTALL ER
Leave this manual
with the appliance.
CO NSU MER
Retain this manual
for future reference.
Note: This kit must be installed
by a qualifi ed installer, service
agency or gas supplier. These
instructions are to be used in
conjunction with the fi replace
main installation instructions.
Barrier Screen
Overview
(Heater and trim sold separately)
534 or 535
3 or 4-sided Trim
601 Standard Front
