802.11n WLAN ADSL2+ Router
Application
Internet Relay Chat (IRC)
Netmeeting (h323)
Real Audio
Ping
Web connections (HTTP, HTTPS)
DialPad
FTP
Telnet
Secure shell (SSH)
Windows Media Services
Gnutella
Kazaa
Windows Terminal Server
DNS
PPTP
Internet Key Exchange
LDAP
GRE
Databeam (T.120)
You can enable access to a common application from a specific PC on your network.
If you want to allow access to an application that is not included on the above list
of common applications, you can create and enable a custom application.

Configuring custom applications

If you want to enable access to an application that does not appear on your de-
vice's default list of common applications you can create a custom application.
In order to create a custom application, you must know:
• the protocol used by the application (e.g., TCP, UDP and so on)
• the primary port or range of ports used by the application
• whether the application requires a trigger, and if so, the secondary port or
range of ports used by the application
• the address translation type used by the trigger
Your application provider or games manufacturer should provide you with these
details.
Port Forwarding for FTP
In this example configuration, a custom application called FTP Server using TCP
port 21 is created.
82
www.modecom.eu
TCP port UDP port
number number
194 194
1720 N/A
N/A 1719
1731
N/A
522
544 7070 544 6770 false
N/A (ICMP) N/A (ICMP) false
80, 443 N/A
51210 N/A
51200
N/A
51201
21 N/A
23 N/A
22 N/A
1755 1755
6346 N/A
1214 N/A
3389 N/A
N/A 53
1723 1723
N/A 500
389 N/A
N/A (GRE) N/A (GRE) false
1503 N/A
Trigger re-
quired?
false
true
true
false
false
true
true
false
false
false
false
false
false
false
false
false
false
false
false
