Modecom MC-4220 User Manual page 100

802.11n WLAN ADSL2+ Router
SSDP Discovery Service is enabled on a default installation of Windows XP. To
check if it is enabled on your system, look in Control Panel > Administrative Tools >
Services).
Installation procedure
To install the Control point software on Windows XP, follow the steps below:
1. In the Control Panel, select "Add/Remove Programs".
2. In the "Add or Remove Programs" dialog box, click the "Add / Remove Windows
Components" button.
3. In the "Windows Component Wizard" dialog box, scroll down the list to display
the "Networking Services" entry. Highlight (select) the entry, and click on the "Details"
button.
4. The "Networking Services" window is displayed.
The subcomponents shown in the Networking Services window will be different
depending on if you are using Windows XP, Windows XP (SP1), or Windows XP
(SP2).
If you are using Windows XP SP2, the Networking Services window will display the
following list of sub-components:
5. Select the following entries from the "Networking Services" window and then
click "OK":
If you are using Windows XP, select:
• "Universal Plug and Play".
If you are using Windows XP SP1, select:
• "Internet Gateway Device discovery and Control Client".
• "Universal Plug and Play".
If you are using Windows XP SP2, select:
100
www.modecom.eu
