ArcFeed
200, 300, 300P, 300RC
EN
Operating manual • English
FI
Käyttöohje • Suomi
SV
Bruksanvisning • Svenska
NO
Bruksanvisning • Norsk
DA
Brugsanvisning • Dansk
DE
Gebrauchsanweisung • Deutsch
NL
Gebruiksaanwijzing • Nederlands
FR
Manuel d'utilisation • Français
ES
Manual de instrucciones • Español
PL
Instrukcja obsługi • Polski
RU
Инструкции по эксплуатации • По-русски
ZH
操作手册 • 中文

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ArcFeed 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Kemppi ArcFeed 200

Summary of Contents for Kemppi ArcFeed 200

  • Page 1 ArcFeed 200, 300, 300P, 300RC Operating manual • English Käyttöohje • Suomi Bruksanvisning • Svenska Bruksanvisning • Norsk Brugsanvisning • Dansk Gebrauchsanweisung • Deutsch Gebruiksaanwijzing • Nederlands Manuel d’utilisation • Français Manual de instrucciones • Español Instrukcja obsługi • Polski Инструкции...
  • Page 3 OperAting mAnuAl english...

  • Page 4: Table Of Contents

    COntents preFACe ................................ General ................................. About voltage-sensing technology ....................Introduction ..............................BeFOre use .............................. Connecting the cables ..........................Selecting the welding wire ........................Mounting the wire spool ........................Installing the MIG/MAG welding gun .................... mAChine settings ........................Setting the maximum wire feed speed ..................

  • Page 5: Preface

    This operating manual contains important information on the use, maintenance and safety of your Kemppi product. The technical specifications of the equipment can be found at the end of the manual. Please read the manual carefully before using the equipment for the first time. For your own safety and that of your working environment, pay particular attention to the safety instructions in the manual.

  • Page 6: Introduction

    The Kemppi ArcFeed is a voltage sensing wire feeder for MIG/MAG welding. It can be combined with a variety of power sources of various brands, also with the ones designed for MMA welding. The recommended power sources to be used with Kemppi ArcFeed are Kemppi Master 5001 and Kemppi Master MLS 3500.

  • Page 7: Before Use

    2.4 mm with the 300P model • Solid wires 1.0–1.6 mm In Kemppi ArcFeed 200 you can use 200mm wire spools. In models 300, 300P and 300RC, you can use 300 mm wire spools. mOunting the wire spOOl model 200: Open the locking nut (A) of the spool holder.

  • Page 8: Installing The Mig/Mag Welding Gun

    Feed speed The maximum wire feed speed of Kemppi ArcFeed is by default 18 m/min. This is enough for most welding work. However, if you need higher speed, you can raise it to 25 m/min by replacing the gear wheel D28 with a larger one, model D40.

  • Page 9: Adjusting The Pressure Of The Feed Rolls

    Adjusting the spOOl BrAke The Kemppi ArcFeed is equipped with a spool brake to prevent the wire from unwinding and tangling when the spool stops rotating at the end of the weld. The need for spool brake force is increased with the increase of the wire feed speed.

  • Page 10: Reversing Polarity

    There are different feed rolls for different welding wires. Also, each feed roll has two grooves for different wire sizes. The Kemppi ArcFeed is equipped with standard feed rolls, which are equipped with plain grooves. These feed rolls can be used in welding with all kinds of wires. There are, however, following feed roll groove shapes available for special purposes: • Knurled groove is designed for cored wires and steel wires.
  • Page 11 to change feed rolls, do the following: Remove the feed rolls by unscrewing their fixing screws. Insert the new feed rolls into their place. Select the right groove according to the wire you are using. See the instructions below. Fasten the feed rolls with their fixing screws and drive the wire into the welding gun as instructed in chapter 2.4 'Installing the welding gun' .

  • Page 12: Using The Machine

    Before starting to use the Kemppi ArcFeed wire feeder, you must be aware of the power source type you are using ( either CC, constant current, or CV, constant voltage). The suitable welding wire for the welding application must also be loaded in the feeder. For more information, see Chapter 3.

  • Page 13: Selecting The Welding Gun Operating Mode

    At the power source, select the correct values for welding voltage and current, if available. Use the control knob of the Kemppi ArcFeed to enter the necessary WFS setting at the feeder. The value is shown on the display. 4.1.3 selecting the welding gun operating mode With the switch (2) you can set the MIG welding gun to either two-sequence (2T) or four- sequence (4T) mode.

  • Page 14: Changing The Wire Feed Speed Adjustment Scale

    how to use the welding gun in 2t operating mode: Press the gun trigger down to start welding. Release the gun trigger to stop welding. how to use the welding gun in 4t operating mode: Press the gun trigger down to start the flow of the shielding gas. Release the trigger to start welding.

  • Page 15: Using The Inside Controls

    The Kemppi ArcFeed 200 wire feeder should never be hanged by its handle. Use a special hanging frame for hanging it to a welding beam or other. See 'Accessories' in Chapter 'Ordering numbers' at the end of this manual.

  • Page 16: Maintenance

    We recommend that you schedule a service inspection of your welding machine every six months. An authorised Kemppi service agent will inspect and clean your machine, ensuring that all power connections are tight and secure. Power connections can become loose and oxidised with frequent and high changes in temperature.

  • Page 17: Ordering Numbers

    Kemppi ArcFeed 300P 6120310 Kemppi ArcFeed 300RC 6120301 Accessories Gas flow regulator W000364 Hanging frame for ArcFeed 200 6185285 KFH 1000 hanger ArcFeed 300 and 300P 6185100 Protection slides for ArcFeed 200 6185286 Protection slides for ArcFeed 300 and 300P...

  • Page 18: Technical Specifications

    Kemppi ArcFeed 300/300RC 300P Rated power (W) Welding wire types Flux-cored wires, ø (mm) 1.2…2.0 1.2…2.0 1.2…2.4 Innershield wires, ø (mm) 1.6…2.0 1.6…2.0 1.6…2.4 Solid wires, ø (mm) 1.0…1.6 1.0…1.6 1.0…1.6 Loadability (A) 60 % ED 80 % ED...
  • Page 20 78681 EPONE CEDEX myynti.fi@kemppi.com info.ru@kemppi.com FRANCE Tel +33 1 30 90 04 40 KEMPPI SVERIGE AB KEMPPI, TRADING (BEIJING) COMPANY, Telefax +33 1 30 90 04 45 LIMITED Box 717 sales.fr@kemppi.com Room 420, 3 Zone, Building B, S-194 27 UPPLANDS VÄSBY No.12 Hongda North Street,...
