You will need to adjust your chair from time to time for best performance
(especially if you alter the original settings). This chart gives you a first solution, then
a second and a third if needed. You may need to look farther to find the best solution
for a specific problem.
NOTE– To keep track of your progress, make only ONE change at a time.
Make sure tire pressure is correct and equal in both rear tires and
front caster tires, if pneumatic.
Make sure all nuts and bolts are snug.
Make sure all spokes and nipples are tight on radial spoke wheels.
Use Tri-Flow Lubricant (Teflon
connections and parts.
Check for proper caster plate adjustment. See instructions for
caster plate adjustment.
Add a spacer washer between the plastic saddle and the caster plate
on the top of the left caster plate.
Add a spacer washer between the plastic saddle and the caster plate
on the top of the right caster plate.
Add a spacer washer between the plastic saddle and the caster plate
on the bottom right caster plate retaining bolts.
Add a spacer washer between the plastic saddle and the caster plate
on the bottom right caster plate retaining bolts.
Make sure there is an equal number of camber washers on each axle
plate.
Make sure both front casters touch the ground simultaneously. If
they do not, add the proper spacers between the bottom bearing of
the caster plate and fork stem nut until they do. Make sure you
check for this problem on a flat surface.
930575 Rev. A
X . T r o u b l e s h o o t i n g
SOLUTIONS
® -based) between all modular frame
X I . M a i n t e n a n c e
A. INTRODUCTION
1. Proper maintenance will improve performance and extend the useful life
of your chair.
2. Clean your chair regularly. This will help you find loose or worn parts
and make your chair easier to use.
3. Repair or replace loose, worn, bent or damaged parts before using this chair.
4. To protect your investment, have all major maintenance and repair work done
by your authorized supplier.
B. MAINTENANCE CHART
CHECK...
Tire inflation level
Wheel locks
All fasteners for wear and tightness
Armrests
Axle and axle sleeves
Quick-Release Axles
Wheels, tires and spokes
Casters
Anti-tip tubes
Frame
Upholstery
Service by Authorized Supplier
