Laars LMC User Manual
Mascot ii wall mounted, modulating boiler combination boiler and water heater
Hide thumbs
Also See for LMC:
- Installation and operation instructions manual (52 pages) ,
- Installation and operation instructions manual (52 pages) ,
- User manual (9 pages)
Table of Contents
Advertisement
Quick Links
User's Manual
FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,
qualified in hot water boiler and heater installation and maintenance. Improper installation and/or operation
could create carbon monoxide gas in flue gases which could cause serious injury, property damage, or
death. Improper installation and/or operation will void the warranty.
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
nearby phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency, or gas
supplier.
WARNING
User's Information for
M
ASCOT
Wall Mounted,
Modulating Boiler
Model LMH
125 MBTU/h
Combination
Boiler and Water Heater
Model LMC
125 MBTU/h
AVERTISSEMENT
Assurez-vous de bien suivres les instructions
données dans cette notice pour réduire au
minimum le risque d'incendie ou d'explosion
ou pour éviter tout dommage matériel, toute
blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones dansle bâtiment où vous êtes.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le sservice des incendies.
L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié ou
par le fournisseur de gaz.
Document 1239A
II
®
Advertisement
Table of Contents
Related Manuals for Laars LMC
Summary of Contents for Laars LMC
- Page 1 125 MBTU/h Combination Boiler and Water Heater Model LMC 125 MBTU/h FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician, qualified in hot water boiler and heater installation and maintenance. Improper installation and/or operation could create carbon monoxide gas in flue gases which could cause serious injury, property damage, or death.
-
Page 2: Familiarizing Yourself To The Laars Mascot Ii
Page 2 LAARS Heating Systems CONTENTS Familiarizing yourself to the Laars Mascot II ....2 1. Caring For Your Mascott II ........3 2. Filling, Shut Down and Restart .......3-4 3. Digital Display and Control ........5-7 FAMILIARIZING YOURSELF TO THE To open the front panels. Remove these two phillips screws, and ASCOT fold lower door down. -
Page 3: Caring For Your Mascott Ii
User’s Manual - Mascot II Boilers and Water Heaters Page 3 2. Filling, Shut Down and Restart 1. Caring For Your Mascot II Your Mascot II will require very little 2.1 Filling the Boiler System maintenance. However, as with any fine appliance Ensure the system is fully connected. -
Page 4: Shutting Down Mascot Ii
Instead, shut off the gas supply at a location external to the boiler. FOR SERVICE Contact your installing contractor, gas utility, Laars dealer, or call Laars for the nearest authorized representative in your area. -
Page 5: Digital Display And Control
Mascot II application: Honeywell AM100- control. They are USER, SETUP and DIAGNOSTIC. US-1. Contact Laars for additional recommended models. The names of these modes gives you an idea of the levels of control. A USER might be the homeowner or... -
Page 6: High Limit
Caution the building’s heating loop. Only after the value shifts position will the firing sequence begin. Scalding Risk: Laars recommends the use of a thermostatic mixing valve at domestic hot water outlet (boiler location) to reduce potential for 3.3 Modulation Control scalding. - Page 7 User’s Manual - Mascot II Boilers and Water Heaters Page 7 3.8 Lead Lag / Cascading Lead Lag/Cascading allows multiple boilers to be connected together and controlled from one common sensor input. Up to 8 boilers can be connected together in a single system. To setup Lead/ Lag or cascading operation there are several settings in the “setup”...
- Page 8 (Customer Service, Service Advisors) 20 Industrial Way, Rochester, NH 03867 • 603.335.6300 • Fax 603.335.3355 (Applications Engineering) 1869 Sismet Road, Mississauga, Ontario, Canada L4W 1W8 • 905.238.0100 • Fax 905.366.0130 www.Laars.com Litho in U.S.A. © Laars Heating Systems 1212 Document 1239A...
