HTC Apache User Manual page 86

2. Tap New. By default, the LEAP screen displays data that you entered previously.
However, you can modify or delete the data as required by tapping Modify or Delete.
3. Enter the SSID (Service Set Identifier).
4. Enter the user name, password, and domain.
5. Select an Authentication Type. By default, the Authentication Type for your device is
Open System.
Note For LEAP to work correctly, both the access point and the receiving device (your device)
must be set with the same SSID, user name, and password.
Check for a Wireless LAN signal
You can check the current wireless connection status from the following three screens of
your device:
• Today screen. If your device detects a WLAN network connection, the WLAN
connection icon appears at the top of the Today screen.
• Wireless LAN Main screen. The current connection status and signal quality for each
specific wireless channel appears on the Wireless Manager screen with the current
configuration.
• Configure Wireless Networks screen. This screen displays the wireless networks
currently available, and allows you to add new ones if available.
Wireless LAN Main screen
|
86 Getting Connected
Configure Wireless Networks screen
