1 Stylus and Stylus Slot
2 Flash
3 Camera Lens
External Antenna
4
Connector
5 Self-Portrait Mirror
6 RESET Button
7 Sync Connector
8 Earphone Jack
9 Microphone
10 CAMERA Button
Accessories
AC adapter
USB cable
Stereo-wired headset with
volume control jog dial and
Send/End button
USB cradle
Use the stylus to write, draw, or select items on the touch screen.
Allows you to capture images even in a dark environment. To turn on
the flash, tap the Flash icon (
The camera lens on your device supports two shoot modes: Wide-
angle mode (normal) and Macro mode (close-up). To change the
shoot mode, push the switch up for wide-angle mode (
for macro mode ( ).
You can connect your device to an external antenna to utilize the
superior reception quality.
Position your device until this mirror reflects the image you want to
capture.
With the stylus, press the Reset button to soft-reset your device.
Use this connector for synchronizing data or recharging the battery.
Allows you to listen to audio media or use the phone's hands-free kit.
Speak into the microphone when receiving or making a phone call or
voice recording.
Press and hold for two seconds to launch Camera mode. When in
Camera mode, press this button to take a picture.
Recharge the device battery.
Connect your device to a PC and synchronize data.
Pick up and hang up incoming and outgoing calls.
Allows you to recharge your device and the second battery (if have),
as well as using ActiveSync to synchronize data between your device
and the PC.
• To recharge the device (or battery), connect the cradle to the
electrical outlet.
• To synchronize, connect the cradle to the USB port on your PC.
) when in Camera mode.
Getting Started
) or down
|
