Electrical power network specification

A 115 - 230 V AC 3-phase power source (EN 61010 over-voltage category III or less)
is required. An AC power filter is required to comply with the CE directive for which
the MicroFlex e150 was tested (see
Description
Nominal input voltage
Minimum input voltage
Maximum input voltage
Nominal input current
@ maximum rated output current
Nominal DC-bus voltage
@ 230 V AC input
Frequency
Imbalance
Fundamental power factor
Network type
Short circuit current protection
(UL 508C)
* The MicroFlex e150 will operate at lower input voltages, although the drive will trip if
the DC-bus voltage falls below 50 V or 60% of the no-load voltage, whichever occurs
first.
on page 153).
CE marking
Unit
1Φ
V AC 115 or 230
105*
250
3 A 6 A
A 7.5 15
305
48 to 63 Hz, maximum rate of change 17%/s
0.98 (at nominal load)
TN (grounded) systems.
Corner grounded TN, and IT (ungrounded)
systems not allowed.
The drive is suitable for use on a circuit
capable of delivering not more than 5000 A
symmetrical amperes (rms) at 230 V
maximum when protected by fuses given in
the fuse table on page 136.
Technical data 129
AC input
3Φ
115 or 230
105*
250
9 A 3 A 6 A
22 4 8
321
Max. ± 3% of nominal
phase to phase input
voltage
9 A
12
