VBR-rt (Varible Bit Rate real-time) is intended for real-time applications, such as compressed
voice over IP and video comferencing, that require tightly constrained delays and delay variation.
VBR-rt is characterized by a peak cell rate (PCR), substained cell rate (SCR), and maximun burst
rate (MBR).
VBR-nrt (Varible Bit Rate non-real-time) is intended for non-real-time applications, such as FTP,
e-mail and browsing.
PCR (Peak Cell Rate) in kbps: The maximum rate at which you expect to transmit data, voice and
video. Consider PCR and MBS as a menas of reducing lantency, not increasing bandwidth. The
range of PCR is 384kbps to 11392kbps
SCR (Substained Cell Rate): The sustained rate at which you expect to transmit data, voice and
video. Consider SCR to be the true bandwidth of a VC and not the long-term average traffic rate.
The range of SCR is 384kbps to 11392kbps.
MBS (Maximum Burst Size): Refers to the maximum number of cells that can be sent at the peak
rate. The range of MBS is 1 cell to 255 cells.
Username : Enter the user name exactly as your ISP assigned.
Password: Enter the password associated with the user name above.
Password confirm: Enter the password again for confirmation.
Idle Time: You can specify an idle time on this field when you don't want the connection up all the
time.
IP type: A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not fixed;
the ISP assigns you a differnet one each time you connect to the Internet.
Press Finish to finish setting.
The screen will prompt the parameters that will be written in NVRAM. Check the parameters before
writing in NVRAM.
Press Restart to restart the router working with new parameters or press continue to setup other
parameters.
4 . 2 . 3 B r i d g e
4 . 2 . 3 B r i d g e
If you want to setup advanced filter function while router is working in bridge mode, you can use
BRIDGE menu to setup the filter/blocking function.
Click Bridge to setup.
