TaiwanSys G.SHDSL.bis User Manual page 25

Gateway: 192.168.0.254 (The Gateway IP is provided by ISP.)
Host Name: SOHO
Some of the ISP requires the Host Name as identification. You may check with ISP to see if your
Internet service has been configured with a host name. In most cases, this field can be ignored.
WAN1:
VPI: 0
VCI: 32
Encap: Click LLC and than Click Next to review
Review
The screen will prompt the newly configured parameters. When using bridge mode, the protocol
mode must be set to Ethernet over ATM (EoA). Checking the parameters and Click Restart. The
router will reboot with the new setting or Continue to configure other parameters.
G.SHDSL.bis Router User Manual V0.01
24
