3 . 2 I n s t a l l
3 . 2 I n s t a l
!
To avoid possible damage to this Router, do not turn on the router before Hardware Installation.
Connect the power adapter to the port labeled DC-IN on the rear panel of the product.
Connect the Ethernet cable.
Note: Both 1-port router and 4-port router supports auto-MDI/MDIX switching so both straight
through and cross-over Ethernet cable can be used.
Connect the phone cable to the router and the other side of phone cable to wall jack.
Connect the power adapter to power source inlet.
Turn on the PC or NB to configure the Router.
G.SHDSL.bis Router User Manual V0.01
t h e S H D S L . b i s R o
l t h e S H D S L . b i s R o
u t e r
u t e r
16
