Percy Doughty & Co.
Imperial Point
Express Trading Estate
Stone Hill Road
Farnworth
Bolton
BL4 9TN
Telephone 01204 868550
Fax 01204 868551
email sales@percydoughty.com
web www.percydoughty.co.uk
16
FIREFOX 12
INSTALLATION AND OPERATING INSTRUCTIONS
(to be left with the householder)
The Firefox Stove operates at very high temperatures. All persons including children
and the infirm should be warned of this and not be allowed to touch any surfaces
whilst in use. The operator must use the tools provided. The mitten provided is a tool.
FIREFOX
CAST IRON MULTI-FUEL STOVE
V 5.2
Conforms to EN13240:2001
Constructional Requirements
APPROVED
Advertisement
Table of Contents
Related Manuals for Percy Doughty & Co FIREFOX 12
Summary of Contents for Percy Doughty & Co FIREFOX 12
- Page 1 FIREFOX CAST IRON MULTI-FUEL STOVE V 5.2 Conforms to EN13240:2001 Constructional Requirements FIREFOX 12 INSTALLATION AND OPERATING INSTRUCTIONS (to be left with the householder) Percy Doughty & Co. Imperial Point Express Trading Estate Stone Hill Road Farnworth Bolton BL4 9TN...
-
Page 2: Parts List
A—Height Flue Key To Dimensions B—Width E—Depth C—Centreline of Flue F—Rear to Centre of Top D—Height To Centre of Rear Flue Refuel Firefox 12 Output. Burning Rate Fuel Load Efficiency Max kW Interval Extract From Test Results Kg/hr Output 1.52 10.0... - Page 3 Firefox 12 Parts List Typical Installation Into Infilled Masonary Fireplaces FFX12003 Stove Top FFX12002 Stove Base FFX12004L Stove Door Left Hand FFX12004R Stove Door Right Hand FFX12003E Expanding Flange FFX12005 Grate Outer FFX12005B Grate Inner Bars (10 pcs) FFX12007F Stove Baffle Plate Frame...
- Page 4 Assembly Of Stove Typical Installation For Inglenook Fireplaces Remove legs, collar and blanking plate from stove and fit in desired position. The collar Inglenook fireplaces can have very large bore chimneys. Check with can be fitted top or rear. your installer—you may need a stainless steel flexible liner for solid fuel fitting.
-
Page 5: Operating Instructions
Ideally, the old fireplace should be filled in so that there is a smooth streamlined entry Typical Rear Flue Installation with clean out door into the flueway. The length of any horizontal run of the flue pipe must not exceed the flue outlet diame- ter on the stove—150mm. -
Page 6: Installation Diagrams
The Firefox 12 is fitted with a tertiary (third) air system. Air is bled into the stove from the rear panel via an air duct over the rear brick. Its function is to ignite unburned gasses and assist clean burning. - Page 7 at least 12 months, with free air movement around the sides of the stack to enable it to dry out. Burning wet or unseasoned wood will create tar deposits in the stove and chim- 3) Unburnt Fuel In Firebox ney and will not produce a satisfactory heat output. Insufficient air reaching fuel.
-
Page 8: General Maintenance
cleaning more difficult. Wet logs on heated glass, a badly aimed poker or heavy slam- Should any difficulties arise over fuel quality or suitability, consult your local supplier or ming of the doors could crack the glass panels. The glass will not fracture from heat. the Solid Fuel Advisory Service.
