Firefox 5CB (Clean Burn)
DEFRA APPROVED FOR BURNING WOOD IN A SMOKE CONTORLLED AREA
CE APPROVED.
Clean burn cast iron wood burning stove
Installation & operating instructions. To be left with user.
This appliance must be installed by a competent person and must
comply with all building regulations including those referring to local
authority by-laws, National and European Codes of Practice . Unless the
installer is qualified to approve the installation, then approval must be
sought from your local building control officer. It is an offence under UK
law not to comply with this advice. After installation the appliance should
be ready for use and instruction as to use and control given.
FFXCB 01/10A
Advertisement
Table of Contents
Related Manuals for Percy Doughty & Co Firefox 5CB
Summary of Contents for Percy Doughty & Co Firefox 5CB
- Page 1 Firefox 5CB (Clean Burn) DEFRA APPROVED FOR BURNING WOOD IN A SMOKE CONTORLLED AREA CE APPROVED. Clean burn cast iron wood burning stove Installation & operating instructions. To be left with user. This appliance must be installed by a competent person and must comply with all building regulations including those referring to local authority by-laws, National and European Codes of Practice .
-
Page 2: Health And Safety
Health & Safety - The Firefox 5 CB stove does not contain asbestos. - Do not use in a shared flue. - Do not use this appliance as an incinerator. - Use only the recommended fuel – do not use liquid fuels. - The surfaces, glass panel, and stove pipe reach very high temperatures. -
Page 3: Parts & Assembly
Parts & Assembly Stove Assembly The stove legs will be found inside the stove, they will require fitting. The two front legs have optional positions either at front of ash lip or rearward inline with body panels. Two of the legs have holes for hearth fixing fit these in desired position. ... - Page 4 Item Description Part No Qty 27 Baffle Plate FFX007 CB 1 Items Not Shown on Diagram 28 Glass Panel Seal FFX027 CB 1 29 Door Seal FFX026 CB 1 30 Operating tool FFX029 CB 1 31 Mitten FFX1 CB 1 32 Door Catch FFX017 CB 1 33 Door Glass Retaining Tabs FFX019 CB 4 34 Hinge Pin FFX028 CB 2 35 De‐ashing Tool FFX039 CB 1 ...
-
Page 5: Installation
Installation Check the chimney is in good condition, dry, free from cracks and obstructions. The diameter of the flue should not be less than 150mm and not more than 230mm. If any of these requirements are not met, the chimney should be lined by a suitable method. - Page 6 Installation Continued The stove can be recessed in a suitable sized fireplace but a permanent free air gap of at least 100mm must be left around the sides and top to obtain maximum heat output and for access to the rear of the stove. There should not be any combustible material within a distance of 450mm from any surface of the stove.
- Page 7 Operating Instructions The appliance has been extensively tested and meets all the requirements necessary to burn wood in smoke controlled areas and is DEFRA approved. If the appliance is installed, operated and regularly serviced correctly it will offer many years of reliable service.
-
Page 8: General Maintenance
Operating Instructions Notes on Wood Burning - Wood burns best on a bed of ash and it is therefore only necessary to remove surplus ash from the grate occasionally. Burn only dry, well seasoned wood, which should have been cut, split and stacked for at least 12 months, with free air movement around the sides of the stack to enable it to dry out. - Page 9 General Maintenance Stove Body The stove is finished with a heat-resistant paint and this can be cleaned with a soft brush. Do not clean whilst the stove is hot; wait until it has cooled down. The finish can be renovated with a suitable brand of paint. Glass Panels Clean the glass panel when cool with a proprietary glass cleaner.
-
Page 10: Troubleshooting
Trouble Shooting POOR HEAT OUTPUT A) Stove too small for a room. Seek advise from a Qualified Heating Engineer as to (KW) output required for room size as a guideline the volume of the room in cubic feet divided by 500 i.e. room 15’x15’x8’ would require 3.6kw approx. B) Chimney and/or flue pipe restricted, room ventilation restricted. -
Page 11: Installation Diagrams
Installation Diagrams Typical Top Flue Installation using steel closure plate incorporating clean out door for chimney sweeping. ... - Page 12 Installation Diagrams Typical Installation For Inglenook Fireplaces Inglenook fireplaces can have very large bore chimneys. Check with your installer – you may need stainless steel flexible liner for solid fuel fitting.
- Page 13 Installation Diagrams Typical Installation Into In Filled Masonry Fireplaces ...
-
Page 14: Specifications
Specifications Dimensions may vary slightly. The manufacturer reserves the right to adjust them without notice. Technical Information Nominal Heat Output Efficiency Flue Gas Temp ˚C Refuel Period Hour Sides Safe Distance to Combustibles Rear Flue Outlet Size Flue Gas Mass Flow CO emission at 13% O2 0.36...
