Spreading Wings S800
User Manual
V 1.0
www.dji-innovations.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spreading Wings S800 and is the answer not in the manual?

Questions and answers

Related Manuals for dji Spreading Wings S800

Summary of Contents for dji Spreading Wings S800

  • Page 1 Spreading Wings S800 User Manual V 1.0 www.dji-innovations.com...

  • Page 2: Disclaimer

    Read this disclaimer carefully before using Spreading Wings S800. By using this product, you hereby agree to this disclaimer and signify that you have read them fully. Spreading Wings S800 is an excellent multi-rotor. With a good autopilot, it will offer tremendous flight features. Despite the controller of DJI...

  • Page 3: Table Of Contents

    Contents Disclaimer ........................2 S800 Profile ........................2 Contents .........................3 Product Usage Cautions....................4 In Box ..........................5 Tools Needed .........................5 Center Frame Wiring ......................6 Mount Center Frame ......................7 Mount Frame Arms ......................8 Mount Bi-pod ........................ 10 Assembly ........................12 ESC Sound ........................13 Specifications .......................

  • Page 4: Product Usage Cautions

     Make sure the propellers and the motors are installed correctly and firmly before flying.  Make sure all parts of S800 are in good condition before each flight. Do not fly with wore or broken parts.  Strongly recommend you use DJI parts as much as possible.

  • Page 5: In Box

    In Box Center Frame 800CF×1 Frame Arm 800FA×6 H Frame 800HF ×1 T Frame 800TF×2,Aluminum Ring 800AR×2 Base Pipe 800BP×2 Bi-pod Drawbar 800BD×4 Silicone Rubber Damper 800SRD×4 Nonslip Damper 800ND×4 3-PIN Servo Cable 800SC ×1 Screw Package 800SP ×1 Hexagonal screws: M2.5×5 Hexagonal socket head cap screws: HC-M2.5×5, HC-M2.5×8, HC-M3.0×22 Adhesive Velcro...

  • Page 6: Center Frame Wiring

    Center Frame Wiring The top board is power distribution board, and the bottom board is for loading autopilot system components. Buckle Top Board Bottom Board Slot Aircraft Nose Top Board Mark Motor clock-wise Mark Motor number XT60 Female To Gimbal ESC signal outlet Circuit line To main controller...

  • Page 7: Mount Center Frame

    Step1: Mount IMU module into IMU position in the center frame. Ensure IMU casing is out of touch the top board edge, as vibration can cause IMU mal-function. Step2: Please mount DJI Autopilot System parts onto the bottom board (not including GPS modules). Please remove all the screws from the bottom board first if necessary.

  • Page 8: Mount Frame Arms

    Mount Frame Arms Step 1 Step 2 800CF　×1 Copper contacts 800FA　×6 Propeller Screw Cover Motor Motor rotation direction Clock-wise Counter clock-wise Green Step 3 Step 4 Step 5 800CF　×1 800CF　×1 800FA　×6 800FA　×6 Vertical Horizontal Horizontal Step1: Check arms. (1) Make sure copper contacts are in good condition without bend or severe wear. (2) Make sure propellers are without crack, and screws in propeller cover tight.
  • Page 9  Slowly rotate the frame arm to prevent from breaking the copper contacts.  Please refer to to ensure the arm is perfectly positioned.  Make sure use appropriate strength to press down the buckle correctly.  Do not hot plug arms. ...

  • Page 10: Mount Bi-Pod

    Mount Bi-pod Step1 Step2 (Fix, but not tighten screws) Step3 H frame bulges outwards T frame n otch Step1: Mount T frame 800TF and base pipe 800BP. (1) Put nonslip damper 800ND through the base pipe. (2) Put the base pipe into T frame until the head of nonslip damper is embedded into T frame. (3) Embed the other nonslip damper into the T frame.
  • Page 11 HC-M2.5×5 (Fig.②) to drawbar and aluminum ring 800AR. Step3: Mount H frame and T frame. (1) Insert T frame through aluminum ring until it plugs into H frame. (2) Fix T frame notch into H frame bulges outwards, make sure T frame will not move. (3) Put the bi-pod on the flat floor to adjust H frame and T frame.

  • Page 12: Assembly

    Notices:  Ensure all knobs on the H frame aligned to the marks, and they would go through the arms successfully. Tips:  It is convenient for you to carry S800 by quick disassembly (Frame, Bi-pod, Frame and Bi-pod).

  • Page 13: Esc Sound

    Throttle stick is not at bottom Input signal abnormal B--------B--------B… Input voltage abnormal BB---BB---BB---BB… Tips: DJI ESCs are specially designed for multi-rotors. When use with DJI autopilot systems, you do not have to setup any parameters or calibrate travel range. Specifications Frame Diagonal Wheelbase 800mm...
  • Page 14 Current 40A OPTO Voltage 6S LiPo Signal Frequency 30Hz ~ 450Hz Drive PWM Frequency 24KHz Weight Propeller Material Carbon Fiber Size 15×04in Weight Flight Parameters Takeoff Weight 5.0Kg ~ 7.0Kg Load Weight 0Kg ~ 2.5Kg Power Battery LiPo (6S、10000mAh~15000mAh、15C(Min)) Max Power Consumption 2100W Hover Power Consumption 720W(@ Takeoff Weight 6Kg)

  • Page 15: Appendix

    Appendix For arms Step1 For arms Shim Step2 Motor mount screws Step3 For arms For arms Step1: Remove. Please unscrew the screws on the top. Step2: Tighten. Retighten the motor mount screws on the back to make the motor firmly attached. Step3: Remount.
  • Page 16 Sales: sales@dji-innovations.com Technical support: support@dji-innovations.com Others: info@dji-innovations.com DJI Spreading Wings is registered trademark of Dajiang Innovation Technology Co. Ltd. Names of product, brand, etc., appearing in this manual are trademarks or registered trademarks of their respective owner companies. This product and manual are copyrighted by Dajiang Innovation Technology Co.
