Connect* your DJI Spark to your iPhone/iPad! Then tap the Picture to start!
*you can connect directly to the spark wifi or use the DJI remote (WIFI or OTG connection)
Icons in the Main Screen:
Map View:
• View the last known drone position.
User Guide:
• Brings you to this user guide.
App Information:
•Provides you with information on the app version and other useful information.
Waypoint Mission:
•Shortcut to the Waypoint Mission Manager.
Main Screen

Advertisement

loading

Related Manuals for dji Spark

Summary of Contents for dji Spark

  • Page 1 Main Screen Connect* your DJI Spark to your iPhone/iPad! Then tap the Picture to start! *you can connect directly to the spark wifi or use the DJI remote (WIFI or OTG connection) Icons in the Main Screen: Map View: • View the last known drone position.

  • Page 2: Piloting Screen

    Piloting Screen Fullscreen Mode VR Mode Waypoint Mission Manager App Settings Camera Settings Camera Mode Switch Shutter Button Open Map View (see Spark Position / choose POI)
  • Page 3 Important: The Forward Anti-collision system is active even in PRO MODE (without the remote controller), BUT in this mode the Spark can fly faster than the reaction time / brake distance that the Spark need to avoid forward collision Right Info Panel...

  • Page 4: Flying Modes

    Without the remote controller you can fly in Atti/GPS Mode, or in settings you can activate the PRO MODE, that will allow you to fly your Spark Faster ( similar to remote controller Sport Mode) and also will allow you to fly with out the 100m distance limitation.
  • Page 5 VR Mode In this Mode you will have an immersive flight experience!! Enjoy the First Person View with any VR headset (goggles) You also have onscreen 2 Augmented Reality localizer, one will show you your Position, the other will show you the position of the POI that you can choose on Map. On screen you have all the information that you need! like distance,altitude,speed,video recording state and all batteries level.
  • Page 6 (View from the iPhone Camera) Customise the VR view The View is full customisable to fit all needs, you can adjust the eye width, the vertical position and the dimension of the views When the Drone is Landed follow on screen instruction! Move the left stick to left to enter edit Mode Use the Right Stick to adjust vertical position and...
  • Page 7 AR Localizer You have two Augmented Reality Localizer that will help you orient yourself on the Spark video feed. The green locator will always indicate your position, while the red one will show you the Position and Distance of a Point of Interest that you can choose on Map.
  • Page 8 Settings General Settings Here you can calibrate the Spark and choose some basic settings such as measurement units (imperial / metric) VR settings Basic settings for VR view RTH settings Here you change the Altitude of the RTH also you can set the...
  • Page 9 As soon as you connect your MFI controller to your device via bluetooth the on-screen piloting pads will disappear and you can start to use it! Thumbsticks - move the Spark (piloting Mode2) Directional pad - not used L1 shoulder button - move camera up (pressure sensitive for the speed)
  • Page 10 Autonomous Waypoint Navigation Tap the icon from the main screen of the app or from the piloting screen, to access the Waypoint Mission Manager From here you can access to your previous saved waypoint missions, or create a new one New mission tap New Mission, to start to design your waypoint mission, you will enter to a map view and you are already in “edit mode”...

  • Page 11: Important Note

    (1) Without DJI remote controller, mission are limited to 100m range...
  • Page 12 Altitude: is the altitude that the drone will have when it’s reach the waypoint, (altitude relative to take off point) the drone will gain or loose altitude progressively from previous waypoint altitude. If it’s the first waypoint, the drone will first reach the waypoint altitude (is currently lower) then it will start moving towards the waypoint Let’s add more waypoints: (long tap) as you add more waypoint you will see also draw the path of the mission, and the...
  • Page 13 Insert a waypoint: To insert a waypoint between 2 existing one, you have to “drag” the (+) annotation, touch it for 0,5 sec to start to “drag” then drop it where you want to insert a new waypoint! now let’s add more waypoint before dig in more waypoint’s options here you can...
  • Page 14 see all the available settings for your waypoint mission: on the left you have “mission options”, on the right are “waypoint options”...
  • Page 15 Understanding Waypoint heading In waypoint settings you can change the heading, by default the drone once reach the waypoint will rotate to look towards the next waypoint, you can manually modify the heading angle or choose to point to a POI (point of interest) also you can choose how rotate: “On Waypoint”...
  • Page 16 Gimbal Pitch Angle you can set the gimbal pitch angle, here you can also set “on waypoint” or “progressive” with the same logic explained above for the heading while you edit the gimbal angle, a “target” will appear that show you what will be in the center of the frame, so you can easily adjust it note: keep in mind that the target position is calculate by the altitude and the angle, considering that what you see on map is at the same take off altitude.
  • Page 17 Waypoint Action Here you can set what action (take pics, start recording…) the drone will perform after reached the waypoint (also after complete the heading and gimbal rotations), before proceed to the next waypoint. Waypoint Action require “Stop On Each” as mission flight mode Speed The speed that you set here, is the one that the drone will use from here to the next waypoint.
  • Page 18 Mission Configuration Menu These options will affect the entire mission: Action After Finished: by default it is "RTH", so you do not have to add waypoints to go back. The waypoint Behaviour: “Stop on each” will allow to define waypoint action (such as take pic, start/stop recording) , “Continuous Flight”...
  • Page 19 Point of Interest (POI) Using POI is really easy, tap the “+” button in mission configurator menu, then tap on map to define the position of your POI. In the POI menu on the right, you can delete, move or adjust the altitude of the selected POI, (the altitude is relative to the take of point) You can also mode the POI by dragging the POI annotation on map (long tap to start to drag) Now add a waypoint, then in the waypoint configuration panel, choose the heading to “POI 1”...
  • Page 20 Now add one more waypoint, adding a waypoint next to one that look to a POI, will automatically set it to the same POI. Lock on POI please note: Heading Rotation: when 2 consecutive waypoint have the same “POI”, the heading rotation will be “Lock on POI”...
  • Page 21 Save Mission Once you have done to plan the mission, hit the save button, and the mission is ready to run! on screen will appear a video preview from the drone (if connected) plus all the necessary telemetry. here you can edit again the mission, run the mission, or go back the mission list. In the mission list you will see the mission that you have just saved on top, with a summary and picture preview.
  • Page 22 Run Mission To run a mission choose one from the list, connect the drone and wait for it to have a GPS fix (you will see the drone icon on the map) now, hit the “Rocket” button to start the mission!! and your drone will automatically perform the entire mission.
  • Page 23 Tapping the rocket icon on this mission toolbar will bring you back to the mission view. (2)Require DJI remote controller Mission + VR mode You can combine both functionality of the app, run a mission as explained above,...
  • Page 24 In this case in “mission configuration" it might be useful to choose "manual" both for the heading and for the gimbal, so as to be able to control them live while the drone performs the route! (3)Require DJI remote controller Mission Dimension...
  • Page 25 The drone have a limited memory dedicate to store a waypoint mission, so it can not be too much “big”, the memory occupied by a waypoint vary based on many factor but mainly from the “heading mode”, as indication: if you use all waypoint with “progressive” heading you will able to add up to 99 waypoints in a single mission.
