Available settings are explained as follows:
Item
Enable
Display Name
Physical Mode
Physical Type
Line Speed
Send SMS if line drops
out
Send Mail Alert if line
drops out
Active Mode and
Backup Type
Description
Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Type the description for such WAN interface.
Display the physical mode of such WAN interface.
In such WAN interface, no type can be selected.
Type the line speed for downloading and uploading for such
WAN interface. The unit is kbps.
Use the drop down list to choose one of the profiles which will
be used to notify the administrator when the network connection
is off.
Check the box to enable this function. When the network
connection is off, the system will send a mail alert to notify the
administrator.
Active Mode – Determine the WAN interface will be active for
always (Always On) or be treated as a backup WAN interface
(Backup WAN).
Backup Type – Determine the role of such WAN interface. It
will be changed according to the Active Mode specified.
If you choose Always On as Active Mode, such interface will
be used for access into Internet all the time.
If you choose Backup as the Active Mode, you have to specify
