4 Replacement Procedures
specified style in document.
4.8
Keyboard
Removing the Keyboard
Remove the Keyboard according to the following procedures and Figures 4.13, 4.14, and 4.15.
1. Turn the laptop upside down.
2. Remove the one M2.5x3 and two M2.5x8 screws securing the keyboard.
M2.5×3*1
3. Open the display panel. Gently pick up the keyboard by prying up the plastic sheet from
the ODD bay.
NOTE: There is a hole for prying up the keyboard in the ODD bay.
Error! No text of specified style in document. Error! No text of
M2.5×8*2
Figure 4.13 Removing screws securing the keyboard
[CONFIDENTIAL]
Satellite P770/P775 Series Maintenance Manual
