4.0 - Reading Ranges
Test Code
3 mil Code 39
7.5 mil Code 39
13 mil UPC
4.2 mil Data Matrix
5 mil Data Matrix
6.3 mil Data Matrix
10 mil Data Matrix
20.8 mil Data Matrix
Note: working ranges are a combination of both the wide and high density fields. All samples were high quality codes
and were read along a physical center line at a 10° angle. Default AGC settings were used. Accuracy= +/- 10%.
5.0 - Targeting & Reading Distance
The blue bars are used for aiming, center the bars in the center of a bar code and press the LED button to scan. The
optimal reading distance is approximately 4.0" (10 cm).
CR1000 Performance
Min Inches (mm)
3.9" (100 mm)
2.2" (55 mm)
2.0" (50 mm)
3.7" (95 mm)
3.7" (95 mm)
3.1" (80 mm)
1.6" (40 mm)
1.6" (40 mm)
Max Inches (mm)
5.0" (125 mm)
8.0" (205 mm)
10.8" (275 mm)
4.7" (120 mm)
5.5" (140 mm)
6.3" (160 mm)
7.9" (200 mm)
12.2" (310 mm)
