Summary of Contents for Redsbaby Bounce

  • Page 1 Redsbaby Bounce Instruction Manual...
  • Page 2: Table Of Contents

    General instructions Warranty information Warnings and safety precautions Features and components Assembly instructions Frame Brake component Rear wheels Front swivel wheels Bassinet and bumper Removing the bassinet and bumper Seat and bumper Basket Using your Redsbaby Bounce Folding and unfolding Engaging and releasing the brake Locking the front swivel wheels Adjusting the handle Using the 5-point safety harness Reversing and reclining the seat Reversing the bassinet Using the tether strap Lifting and carrying your Redsbaby Bounce safely 18 Accessories – Assembly and Use Rain cover...
  • Page 3: General Instructions

    General Instructions This document contains important information and must be kept for future reference. Please read thoroughly before commencing assembly and use of your Redsbaby Bounce. Incorrect assembly and use can be dangerous and result in serious injury or even death. There may be slight variations in the design of your product to that shown in the images of this instruction manual.
  • Page 4: Warranty Information

    Warranty information 12 Month Warranty The Redsbaby Bounce and its accessories come with a 12 Month Warranty to cover against faults in materials and workmanship when your products are used under normal conditions, according to our user manuals and technical specifications. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
  • Page 5 How To Make A Warranty Claim Send an email to info@redsbaby.com.au to notify us of your warranty claim. To validate your warranty claim we will require you to include in your email: - a description of the warranty defect including photographs; - your contact details; - attached invoice with order number; and - product batch number (the batch number is printed on a sticker that is located on the crossbar above the shopping basket on the stroller frame). We will respond to your warranty claim within 7 business days and depending on the nature of the warranty claim, arrange collection of the product from your nominated address. Collection will take place on a business day (i.e. not a public holiday or weekend within your state or territory) between 8am and 5.30pm. Please take care to repack the product in secure and stable packaging to avoid any damage occurring in the returns transit. We do not take responsibility for any damage that occurs in transit to and from our pram repairer. Once our pram repairer has received the product they will inspect and confirm the reported defect. We will then contact you with further information surrounding the repair such as the estimated turn around time. If you have any questions, you can contact us at info@redsbaby.com.au.
  • Page 6: Warnings And Safety Precautions

    Warnings and safety precautions Please read the following warnings and safety precautions thoroughly before using your Redsbaby Bounce. Incorrect assembly and use can result in serious injury or death. Always follow safety instructions for assembly, folding and use. Always ensure that your Redsbaby Bounce is correctly assembled and locks are engaged before use. After unpacking, immediately discard any plastic wrapping and packaging materials, as these can lead to a choking hazard. Always use the safety features that come with your Redsbaby Bounce, such as the tether strap, brakes and harness. GENERAL WARNINGS: • To avoid injury or death: Always apply the brakes whenever the Redsbaby Bounce is stationary. • Do not leave children unattended. • Secure the child in the harness at all times. • Do not carry extra children or bags on the Redsbaby Bounce. • Make sure children are clear of any moving parts if you adjust the Redsbaby Bounce, otherwise they may be injured. • Follow the manufacturer’s instructions. • Put on all the brakes whenever you park the Redsbaby Bounce. • Use the harness at all times. • When not in use disconnect shoulder straps from the waist strap and/or buckle. • The harness can form loops which may cause a strangulation hazard. Never leave a harness connected when not fitted to a child in the Redsbaby Bounce. • Use the tether strap to stop the Redsbaby Bounce rolling away. • Do not use the seat or bassinet with any other models of stroller. • Do not use bassinet once the child can sit up unaided. • Only use the bassinet in the flat position. Do not recline. • Do not use any accessories that are not designed for or compatible...
  • Page 7 • Take care when used on stairs or escalators. • Do not use or leave the Redsbaby Bounce near open fire or exposed flame. • Brakes must always be applied when the Redsbaby Bounce is not moving. GENERAL SAFETY PRECAUTIONS: • When the vehicle is being folded and unfolded, there is potential for fingers or parts of the body to be injured and due care should be exercised. • Overloading, incorrect folding or the use of non-approved accessories may cause injury or damage your Redsbaby Bounce. • Ensure you follow the regular maintenance and care instructions included in this manual. Pay special attention to maintenance and care of the brakes. • The Redsbaby Bounce must only be used for one (1) child. • Do not hang bags on Redsbaby Bounce handles, as this can cause it to become unstable. • Do not lift or carry the Redsbaby Bounce when a child is in it. • Do not lift or carry the Redsbaby Bounce when fully assembled. Only lift and carry when folded. • The Redsbaby Bounce is designed for use on flat or gentle sloping surfaces and may be unstable on higher sloping and uneven surfaces. The vehicle may tip over when used incorrectly on steep inclines/declines. • Do not leave the rain cover on without the ventilation window on the front of the rain cover open. • When using your Redsbaby Bounce on stairs or escalators, take care. MAXIMUM WEIGHT LIMITS: • Maximum weight for a child in the bassinet is 9kg (19.8 lbs). • Maximum weight for a child in the seat is 17kg (37.5 lbs). • Maximum weight for items in the pockets on the back of the seat is 1kg (2.2 lbs). • Maximum weight for items in the basket is 4.5kg (10 lbs).
  • Page 8: Features And Components

    Features and components Sticker Label 55mm 1. Handle 9. Bassinet 2. Fold lock 10. Frame 3. Bassinet apron 11. Basket 4. Frame fold 12. Front swivel latches wheels 5. Brake 13. 5-point safety 6. Rear wheels harness 7. Canopy 14. Seat with seat 8. Circular frame liner...
  • Page 9: Assembly Instructions

    Assembly instructions Frame To release the frame from the folded position: 1. Place frame on the ground and position yourself behind the handle bar. 2. Pull back on the two frame fold latches located on either side of the frame simultaneously. 3. Holding the frame on either side of the disengaged frame fold latches, gently lift the frame continuing until the frame locks into place. When the frame has been fully opened, you will hear and feel a firm ‘click’. Sticker Label Sticker Label 55mm 55mm Sticker Label 55mm Brake component Align the brake component with the two rear ends of the pram. Click the brake component into place. Ensure that the brake component is assembled correctly by checking the two silver locking pins located on the underside of the rear brake component are in place.
  • Page 10: Rear Wheels

    Rear wheels Fit the rear wheels on the axle housings located on either side of the rear brake component. You will hear and feel a firm ‘click’ when the wheels are locked in place. IMPORTANT: Ensure you check that the wheels are clicked in correctly by tugging them outwards. Failure to attach the wheels correctly will result in them falling off the pram while in use. To remove, simply press the button in the middle of the wheel to release. Front swivel wheels Fit the front swivel wheels by inserting them into the front wheel locks located at the front of the frame. You will hear and feel a firm ‘click’ when the wheels are locked in place. Assembling the bassinet and bumper Note: Your Bounce will come with the bassinet assembled. WARNING: • Do not use bassinet once the child can sit up unaided. • This bassinet is only approved for use with model Redsbaby Bounce. • The maximum weight of a child that can be carried in this bassinet: 9kgs. • Only use the bassinet in the flat position. Do not recline. 1. Place the bassinet lining in the circular frame with the bottom end of the bassinet lining at the top end of the circular frame. 2. Grip the bassinet lining edge and gently feed into the bottom end of the circular frame. While feeding the edge through the frame channel, use your second hand to place a finger on the entry to the channel and apply slight pressure. This will help feed the edge through smoothly. The edge of the bassinet lining will slide into the channel freely if done correctly. IMPORTANT: Excessive force may result in the lining becoming dislodged from the channel and damaging the circular frame or your bassinet lining. IMPORTANT: Do not continue to apply force or pressure if the bassinet lining edge becomes stuck. Gently pull the lining out and try again.
  • Page 11 PRESS THUMB HERE 3. Feed the top end of the bassinet lining into the circular frame by gripping one side of the edge and gently feeding into the frame channel. Stop when approximately 5cm of the edge has been fed into the frame. 4. Repeat this on the opposite side, again feeding in approximately 5cm of the edge into the channel. 5. Continue to slowly feed small sections of each side of the lining into the frame until the lining is completely in the channel. 6. Secure the Velcro tabs around the top end of the circular frame. PRESS THUMB HERE 7. Place the bassinet board in the bottom of the bassinet liner. Secure using the Velcro tabs located at the top and bottom ends of the bassinet liner. 8. Place the bassinet mattress in the bassinet liner. 9. Zip on the bassinet apron. 10. If desired, attach the bassinet bumper by aligning the ends of the bumper with the two openings on the circular frame. Gently push down into place until your hear and feel a ‘click’ on both sides. Check the bumper bar is locked securely. 11. If desired, attach the canopy by following the instructions on page 17. 12. To place on the frame, push down gently until you feel and hear a ‘click’.
  • Page 12: Removing The Bassinet And Bumper

    Removing bassinet and bumper 1. Remove the bumper by simultaneously pushing the buttons on either side of the bumper. 2. Remove the bassinet apron by unzipping. 3. Remove the bassinet mattress. 4. Remove the bassinet board by releasing the Velcro tabs at the top and bottom ends of the bassinet board and gently lifting out. 5. Release the Velcro tabs at the top end of the circular frame. 6. Grip both hands on either side of the top of the circular frame, wrapping your thumbs inside the frame. 7. Gently remove the bassinet lining from the circular frame by simultaneously sliding both hands downwards using your thumbs. 8. To remove the bassinet lining from the bottom half of the circular frame, grip the bassinet lining where it enters the circular frame channel (this can be on either the left or the right hand side) and using a very gentle force, slowly pull outwards. The lining will slowly side out of the circular frame channel. IMPORTANT: Excessive force may result in the lining becoming dislodged from the channel and damaging the circular frame or your bassinet lining. IMPORTANT: Do not continue to apply force or pressure if the lining becomes stuck. Gently feed the lining back into the channel, and try again.
  • Page 13: Seat And Bumper

    Assembling the seat and bumper WARNING: • Do not use this seat with any other models of stroller. • This seat is only approved for use with model: Redsbaby Bounce. • The maximum weight of a child that can be carried in this seat: 17kgs. 1. Take the fabric seat unit and stretch the head rest section over the top of the circular frame. 2. Pull the rest of the seat unit fabric tightly towards the bottom of the frame. Take the safety straps and hook over the side of the frame. 3. Turn the frame over and then clip both ends of the safety strap together. Tighten if necessary. 4. Secure the four Velcro tabs at the bottom of the seat fabric to the circular frame. 5. Attach the bumper by aligning the ends of the bumper with the two openings on the circular frame. Gently push down into place until you hear and feel a firm ‘click’ on both sides. 6. If desired, attach the canopy by following the instructions on page 17. 7. To place the seat on the frame, push down gently until you feel and hear a firm ‘click’.
  • Page 14: Basket

    Basket IMPORTANT: Maximum weight for items in the basket is 4.5kg. Note: Your Redsbaby Bounce will come with the basket assembled, except for the solid plastic lining/insert. 1. Fold the sides of the fabric basket over the basket rods at the bottom of the stroller frame. Secure by fastening the buttons on both sides. 2. Secure the toggles on all four corners by stretching the elastic around the stroller frame. 3. Place the plastic lining inside the basket. To remove, undo the toggles and unbutton the basket from the basket rods.
  • Page 15: Using Your Redsbaby Bounce

    Using your Redsbaby Bounce Folding and unfolding the Redsbaby Bounce frame WARNING: • Make sure children are clear of any moving parts when you adjust the Redsbaby Bounce, otherwise they may be injured. • Ensure the frame fold locks are engaged correctly before placing a child in the Redsbaby Bounce. To release the frame from the folded position: 1. Pull back on the two frame fold latches located on either side of the frame simultaneously. 3. Holding the frame on either side of the disengaged frame fold latches, gently lift the frame and place on the ground. 4. Continue to lift the handle until the frame fold locks engage. IMPORTANT: When the frame fold locks have been engaged correctly and the frame has been fully opened, you will hear and feel a firm ‘click’. To fold the frame 1. Remove the bassinet or seat unit if attached to the frame. 2. Simultaneously pull back on the frame fold locks while pressing the safety button underneath the lock on the right hand side. Tip: You can rest the handle bar on your waist to provide some resistance if required.
  • Page 16: Engaging And Releasing The Brake

    Safe lifting and carrying of the Redsbaby Bounce frame when folded IMPORTANT: Do not lift or carry the Redsbaby Bounce when a child is in it. IMPORTANT: Do not lift or carry the Redsbaby Bounce when fully assembled. Only lift and carry when folded. 1. Always lift and carry the frame using two hands. 2. Ensure the frame fold latches are engaged. Engaging and releasing the brake The brake is located between the rear wheels of the Redsbaby Bounce. The brake bar is identified by two red components on either end. 1. To engage the brake, press down on the brake bar at the rear of the Redsbaby Bounce with your foot until you feel and hear a ‘click’. 2. To release the brake, lift the brake bar up with your foot until the brake lock disengages. Locking the front swivel wheels 1. Press downwards on the tab buttons located at the front of the wheels until you hear and feel a ‘click’. 2. Push the Redsbaby Bounce forwards until you hear a second click in both front wheels. 2. To unlock, simply lift the tab buttons upwards. When released successfully, you will hear and feel a ‘click’. Adjusting the handle Note: Your handle can be adjusted to five height options.
  • Page 17: Using The 5-Point Safety Harness

    Using the 5-point safety harness WARNING: • Use the harness at all times. • When not in use disconnect shoulder straps from the waist strap and/ or buckle. The harness can form loops which may cause a strangulation hazard. Never leave a harness connected when not fitted to a child in the Redsbaby Bounce. IMPORTANT: For the safety of your child the 5-point safety harness must be properly fitted and adjusted. Follow the instructions and Figure 1 below. 1. Ensure the seat is assembled correctly by following steps on page 13. 2. Ensure the seat bottom is sitting flat on the seat. 3. Slide the shoulder strap clip (A1) onto the waist strap clip (B1) and clip into the center buckle (C).
  • Page 18: Reversing And Reclining The Seat

    IMPORTANT: Do not reverse or recline the seat when a child is in the seat. 1. To recline, press and hold both round buttons on the side of the seat and move into the desired position. When in place, you will hear and feel a firm ‘click’. 2. To reverse, remove the seat unit by pressing the rectaingular release buttons on either side of the seat unit and lift upwards. When the release locks are disengaged, you will hear and feel a firm ‘click’. The seat unit can be fitted either rear or forward facing. Reversing the bassinet IMPORTANT: Only use the bassinet in the flat position. Do not recline. To reverse, remove the bassinet by pressing the rectangular release buttons on either side of the bassinet unit. When the release locks are disengaged, you will hear and feel a firm ‘click’. The bassinet unit can be fitted either rear or forward facing. Using the tether strap WARNING: • Use the tether strap to stop the Redsbaby Bounce rolling away. Attach the tether strap to your wrist at all times when using the Redsbaby Bounce. Lifting and carrying the Redsbaby Bounce safely IMPORTANT: Do not lift or carry the Redsbaby Bounce when a child is in it. IMPORTANT: Do not lift or carry the Redsbaby Bounce when fully assembled. Only lift and carry when folded. For folding instructions, refer to page 13.
  • Page 19: Accessories - Assembly And Use

    Accessories WARNING: • Do not use any accessories that are not designed for or compatible with the Redsbaby Bounce. IMPORTANT: The following accessories are only compatible with Redsbaby Bounce. Do not use with any other model of vehicle. Rain Cover IMPORTANT: Do not leave the rain cover on without the ventilation window on the front of the rain cover open. Note: The canopy must be attached to the Redsbaby Bounce before securing the rain cover. Starting at the back of the canopy, gently pull the rain cover over the bassinet or seat. Ensure the canopy peak is flipped over in the forward position to ensure correct fitting of the rain cover. Peek-a-Boo! Bounce Canopy To assemble: Feed the rods through the canopy. Secure plastic clips by sliding rods inward until firmly in place. Pull elastic loops on the canopy over the hooks on the plastic clips. 1. Clip the canopy onto both sides of the circle frame above the bumper bar. 2. If using the bassinet, stretch the canopy over the top end of the bassinet. If using the seat, stretch the canopy over the top end of the seat and secure by aligning Velcro tabs on canopy with Velcro on seat. Bassinet Apron Secure the bassinet apron by zipping onto the bassinet liner. Tip: Folding back the bassinet apron to see your child. You can unzip either side of the bassinet lining and hook the elastic loops located in the bassinet apron lining to the two metal hooks on either side of the circular frame. This will enable you to see your child while still using the bassinet apron if desired.
  • Page 20: Switch It! Reversible Seat Liner

    Remove the shoulder and crotch padding from the Bounce seat unit harness. Align the reversible seat liner on the Bounce seat unit. Feed the five point safety harness through the respective crotch, waist and shoulder strap holes. If desired, replace the shoulder and crotch padding. Smoooth! Air Tyres Note: Accessory sold separately Fit both tyres on the axle housings located on either side of the rear brake component. You will hear and feel a firm ‘click’ when the wheels are locked in place.To remove, simply press the button in the middle of the wheel to release. Get Organised! Pram Organiser WARNING: • Do not place hot beverages in the pram organiser. Placing hot beverages in your pram organiser creates a scalding hazard and may injure you or your child. Note: Accessory sold separately Secure both Velcro straps around your pram handle bars. Tip: Fits best when handle bar is rotated to the horizontal position. Shoofly! Bounce Insect Net Note: Accessory sold separately Note: The canopy must be attached to the Redsbaby Bounce. Starting at the back of the canopy, gently pull the Shoofly! Bounce Insect Net over the bassinet or seat. Ensure the canopy peak is flipped over in the forward position to ensure correct fitting. Cosy Toes Foot Muff Note: Accessory sold separately Note: The Bounce seat unit must be assembled to attach the Cosy Toes Foot Muff. Secure the Cosy Toes Foot Muff Velcro tabs around the base of the circular frame.
  • Page 21: Maxi-Cosi Capsule Adaptors - Travel System

    Manual. 2. Stand behind your Redsbaby Bounce handle bar, and click the adaptor marked with the ‘R’ symbol into the right-hand side, with the ‘R’ symbol facing outwards. You will hear and feel a FIGURE 2 firm ‘click’ when the adaptor is in place. 3. Repeat with the adaptor with the ‘L’ symbol, clicking it into the left hand side, with the ‘L’ symbol facing outwards. See Figure 2. Securing your Maxi Cosi capsule into your Redsbaby Bounce adaptors: 1. Hold the Maxi Cosi capsule facing you, and using both hands push the capsule down onto the adaptors to click into place. IMPORTANT: To check that the capsule has clicked in correctly, lift the handle of the capsule upwards. See Figure 3. FIGURE 3 To remove your Maxi Cosi capsule from your Redsbaby Bounce...
  • Page 22 To remove your Maxi Cosi adaptors from your Redsbaby Bounce chassis: 1. Press the grey release buttons on each adaptor. When the release locks are disengaged, you will hear and feel a firm ‘click’ and you can lift them upwards to remove.
  • Page 23: Product Care

    • Store the Redsbaby Bounce in a dry, well-ventilated and safe place. • Do not use your Redsbaby Bounce if any screws are loose or missing or if any component is damages.
  • Page 24 YOUR REDSBABY BOUCE ©Copyright 2014 Redsbaby...
