KR200S
USER'S MANUAL
K-array is the new voice that sings
aloud, "outside the choir", and whose
performance is better than any other
products.
Born on-the-road, in the PA world, where
you get no discount, you have to give your
best as fast as you can, often with a
"compressed" budget, K-Array systems
have been designed to give precise
answers to precise needs.
Driven by new generation digital engines,
with power/dimension/weight ratios that
are ten times better than any other
professional products, K-arrays can
deliver the full spectrum of musical styles
with clarity, power, punch, intelligibility
and evenness across both volume levels
and the frequency spectrum. These
systems can be remotely controlled and
come with a sophisticated on-board
software, allowing the user to shape their
performance to taste and needs. Inside
K-array systems you will find something
that only we can offer: the best in
technology, proudly conceived, designed
and produced in Italy. If they were cars,
they would be Ferrari. Don't agree to pay
for a simple brand, claim performance,
and don't believe those who maintain that
these products are only for few people,
the only truth is that K-array systems are
unique, but affordable and within
everybody's reach!
HP Sound Equipment s.r.l.
USER'S MANUAL
ENGLISH
REV. A
