BK Precision 1672 Installation Manual
Triple output power supply
Hide thumbs
Also See for 1672:
- Instruction manual (38 pages) ,
- Instruction manual (23 pages) ,
- Instruction manual (9 pages)
Subscribe to Our Youtube Channel
Related Manuals for BK Precision 1672
Summary of Contents for BK Precision 1672
- Page 1 99 Washington Street Melrose, MA 02176 Fax 781-665-0780 TestEquipmentDepot.com Instruction Manual Model 1672 Triple Output Power Supply...
-
Page 2: Table Of Contents
Contents Section Description Page No. CONTENTS TEST INSTRUMENT SAFETY INTRODUCTION 2.1 INTRODUCTION 2.2 FEATURES Installation 3.1 INTRODUCTION 3.2 UNPACKING 3.3 INPUT POWER REQUIREMENTS 3.4 SYSTEM CONFIGURATION 3.5 INSTALLATION 3.6 OPERATING INSTRUCTIONS Setting the Output Voltage and Current Tracking Mode Operation Connecting Multiple Units and Fixed Output 8 TECHNICAL SPECIFICATIONS CONTROLLS AND INDOCATORS... -
Page 3: Test Instrument Safety
Test Instrument Safety Section 1 - WARNING - Normal use of test equipment exposes you to a certain amount of danger from electrical shock because testing must sometimes be performed where exposed voltage is present. An electrical shock causing 10 milliamps of current to pass through the heart will stop most human heartbeats. -
Page 4: Introduction
2.2 FEATURES INTRODUCTION The Model 1672 is a Triple Output Regulated DC Power Supply that provides one fixed output (5V/ 3A) and two variable outputs (0 – 32V/ 0 – 3A) ratings. The variable outputs can work independently, or in series tracking, or parallel mode. -
Page 5: Installation
Section 3 Installation INTRODUCTION UNPACKING INPUT POWER REQUIREMENTS SYSTEM CONFIGURATION INSTALLATION OPERATING INSTRUCTIONS INTRODUCTION This unit is tested prior to shipment. It is therefore ready for immediate use upon receipt. The initial physical inspections should be made to ensure that no damage has been sustained during shipment. - Page 6 3.5.2 Load Connections Connect the appropriate load between +ve (Red) and –ve (black) terminal. For model 1672 the load connection is same as above while using indepen- dent output. In serial tracking mode of operation, connect the appropriate load between +ve (Red) terminal of master and –ve (black) terminal of slave.
-
Page 7: Setting The Output Voltage And Output Current
(5) output terminals by the accessory leads. Vary the current adjustment knob clockwise until the 1672 current (Red) displays the required current limit. The C.C. LED will be lighted while adjusting the current limit. Remove the accessory lead after current limit adjustment. -
Page 8: Output Current
(Max 240V). The output voltage will be the SUM of twice of set volt- age of the Master. Set all the 1672, which would be connected in serial operation under serial tracking mode as described in serial tracking mode and adjusts to the same output. - Page 9 Section 6 Multiple units in parallel mode The power supply 1672 can be connected two or more units in parallel to obtain a higher current output (Max. 24A only). Set all the 1672 which will be connected in parallel operation under parallel tracking mode as described in parallel tracking mode and ad- just all units to the same output voltage.
-
Page 10: Tracking Mode Operation
Section 7 Technical Specifications Output Parameters Number of Outputs Three ( One fixed and Two variable) Range 0 to 32 Vdc/ 0 to 3A ( variable) and 5V/ 3A (fixed) Max. output power 195VA Constant Voltage Mode Line regulation <0.01% + 5mV Load regulation <0.2% + 10mV Ripple &... -
Page 11: Introduction
Section 8 CONTROLS AND INDICATORS INTRODUCTION FRONT PANEL DESCRIPTION REAR PANEL DESCRIPTION PANEL LAYOUT INTRODUCTION This chapter explains the operating procedure of the unit. The operation is made very simple by providing front panel Potentiometer control. The Front and rear panel description of the instrument is provided first. Then the operating procedure is explained in detail. - Page 12 16. Slave Voltage Indicator Display in full 3-digits Green 0.56” LED. 17. Slave Current Indicator Display in full 3-digits Red 0.56” LED. 18. Voltage Adjustment knob for adjusting Slave output voltage when master power is at C.V. Mode. 19. Current Adjustment knob for adjusting Slave output current when master power is at C.C.
- Page 13 PANEL LAYOUT FRONT PANEL OF 1672 REAR PANEL OF 1672...
-
Page 14: Maintenance
Section 9 Maintenance INTRODUCTION PREVENTIVE MAINTENANCE SERVICE INFORMATION TEST EQUIPMENT REQUIREMENTS INTRODUCTION This chapter gives information about preventive maintenance and ser- vice information of the unit. PREVENTIVE MAINTENANCE Please follow the following preventive steps to ensure the proper op- eration of your instrument. Never place heavy objects on the instrument. -
Page 15: Service Information
SERVICE INFORMATION WHEN THE UNIT IS NOT TURNING ON. Check if the power ON/OFF switch is turned ON. If not, then check the power cord. Please make sure that the power cord is properly connected to the unit. Please also check the main switch. And ensure that the AC supply at your site is the same as the one mentioned at the rear chassis of the unit. - Page 16 TEST EQUIPMENT REQUIREMENTS (only required when doing a performance verification test) The following instruments will be required to test the complete installa- tion of the unit. 1). A 4½ Digit Multimeter for verifying the output voltage and current. 2). A 20 MHz dual channel oscilloscope for verifying the Ripple in the DC Output/s.
- Page 17 Limited One-Year Warranty B&K Precision Corp. warrants to the original purchaser that its product and the component parts thereof, will be free from defects in workmanship and materials for a period of one year from the data of purchase. B&K Precision Corp. will, without charge, repair or replace, at its’ option, defec- tive product or component parts.
