SeQual Eclipse Troubleshooting Manual page 16

6. Loss of External Power or Hot Power Cartridge.
Eclipse Unit has a
NOT Running.
Continued from Previous Page
D. Ensure that the AC/DC Adapter plug is securely plugged into the Eclipse Power Connector, and
the GREEN External Power Icon on the Eclipse Display/Button panel is illuminated.
i. If "Not", the AC or DC Adapter may be faulty...
possible repair.
ii. If "Yes", continue to Step E
E. Push and hold the On/Off button until the unit turns "ON", the Eclipse should sound a 3 second
test beep. All LED's should be LIT. The Red then the Yellow LED's should go out with in
several minutes.
i. If unit starts to alarm - Remove the AC/DC Adapter Unit and hold down the ON/OFF Button
for 5 seconds then release to turn the Unit "OFF". "The AC or DC Adapter of Eclipse may
be faulty.
ii. If "Not" – then proceed to Step F
F. Re-Insert the Power Cartridge and turn the unit "ON". (Repeat Step E)
i. If the unit starts to alarm - Remove the AC/DC Adapter unit and hold down the ON/OFF
Button for 3 seconds to turn the Unit "OFF".
ii. "The AC or DC Adapter or your Eclipse may be faulty.
possible repair..
iii. If "Not" –
continue to use your Eclipse"
Troubleshooting Guide
Troubleshooting Guide
CONTINUOUS ALARM, a
Exchange out the item for evaluation and possible repair.
"Your Eclipse concentrator is running within its normal limits now, you may
11436 Sorrento Valley Road • San Diego, CA 92121 •
RED FLASHING LED, and the Eclipse is
Exchange out the item for evaluation and
Exchange item for evaluation and
www.sequal.com • 858.202.3100
16
