Summary of Contents for Prestigio LIBRETTO PER307
- Page 1 PRESTIGIO LIBRETTO e-Book Reader PER307 www.prestigio.com...
-
Page 2: Table Of Contents
Table of Contents Disclaimer Introduction Package Content Getting Started Charging the Reader Power On/Off, Reset Device, Insert MicroSD Main Menu History Books Music Video Photo Explorer User Manual Settings Creating an Adobe account Installing Adobe Digital Editions (ADE) Authorizing PC and Reader Transferring DRM e-books to Reader Product Specifications Technical Support and Warranty Information... -
Page 3: Disclaimer
Introduction Prestigio Libretto PER307 is an e-book reader with full color TFT display screen 19 cm (7”) diagonal and resolution of 800*600. PER307 supports e-books encrypted with Adobe DRM, as well as FB2, HTML, etc. -
Page 4: Getting Started
Getting Started Previous Page Skip to previous page, Volume down Next Page Skip to next page, Volume up Menu Button Enter the menu options Zoom Button Zoom in/out contents on screen Navigation Pad Navigate through all options “OK”; Play/ Pause “OK”... -
Page 5: Charging The Reader
Getting Started Charging the Reader You need to charge the Reader prior to using it for the first time or when battery power is low. Note: It’s recommended to charge the battery for 8 hours before the first time use. Normally it takes approximately 7 hours to fully charge the device. Recharge the device as soon as possible when the battery is in low-power level shown as icon appears once the battery is fully charged. -
Page 6: Power On/Off, Reset Device, Insert Microsd
Getting Started Power Reader On and Off Press and hold the [Power] button for 5-6 seconds to turn on Reader - it will automatically enter the main menu on Home screen after the start-up screen. It may take a few moments for reader to turn on and load the content. ... -
Page 7: Main Menu
Main Menu The main menu includes History, Book, Music, Video, Photo, Explorer, User Manual, and Settings. Use the Navigation Pad to highlight the desired mode and press “OK” button to confirm. Press to return to previous option. 7’ eBook Reader... -
Page 8: History
Main Menu: History History Files viewed in the past will be displayed on the screen. Press Navigation Pad to navigate to History icon and press “OK” button to enter previously opened files list. At the files list, press to pop up the option menu. - Page 9 Main Menu: History Use the Navigation Pad to select the desired files or press Page Jump Buttons to turn pages if available. Press “OK” button to open file or press to exit the mode. During text playback, press Page Jump Buttons or Navigation Pad to turn pages.
- Page 10 Main Menu: History Item Description Go To Page Press the Navigation Pad to select desired page. Press “OK” button to confirm or press to cancel. Press “OK” button to save the address of the current Save bookmark page. 5 items are available. Highlight the item and press “OK”...
-
Page 11: Books
Main Menu: Books Books Libretto PER307 supports 6 kinds of e-book formats, including .txt, html, fb2, pdb, epub, and pdf. Please make sure it is NOT a DRM protected file, which cannot be read by the E-reader. Press Confirm Button to enter Book mode. - Page 12 Main Menu: Books Use / of Navigation Pad to select the desired file in the books list or press Page Jump Buttons to turn pages if available. Highlight the desired file and press “OK” button to open file. During text playback, press Page Jump Buttons or Navigation Pad to turn pages.
- Page 13 Main Menu: Books Item Description Information Display technical information of the current book. Catalog The book index information is displayed. Highlight desired item and press “OK” button to confirm. NOTE: The Catalog function is only available with files in PDF and EPUB formats with index information Note: Please refer to History part for more detailed instructions of other items.
-
Page 14: Music
Main Menu: Music Music Use the Navigation Pad to select the icon and press “OK” button to enter the mode. The music list will be displayed. It supports WMA, AAC, WAV and OGG files’ formats only. Note: Music files saved on micro SD card are also displayed in the list. Item Description Music play/... - Page 15 Main Menu: Music Highlight Music/Resume Play to enter current playback screen. To play the lists of All Music, Artist, Album, My favorites, Genre and Directories List, press Navigation Pad to select desired track or press Page Jump Buttons to turn pages if available, and then press “OK” button to enter playback screen.
- Page 16 Main Menu: Music Press to pop up the options menu. Highlight Delete/Delete All and press “OK” button to delete current music file or all files in My Favorites. 7’ eBook Reader...
- Page 17 Main Menu: Music On the playback screen, the following operations can be performed. 1. Press / of Navigation Pad to adjust volume level. Press / of Navigation Pad to skip to previous/next track. Press to pause /resume playback. Press and hold / of Navigation Pad to rewind/go forward. Press exit playback screen.
- Page 18 Main Menu: Music 2. Press to enter Music Settings as follows. Use Navigation Pad to highlight item and press “OK” button (repeatedly) to confirm. Press to exit settings. Item Description Repeat Settings Play modes’ settings. Play Settings Play orders’ settings. Microsoft Sound Sound quality settings.
- Page 19 Main Menu: Music It is possible to read books (or view pictures) while playing a track. During music playback, press to enter background music mode, in which you can use the device with playing music. Press to display play bar and press it again to pause /resume playback any time.
-
Page 20: Video
Main Menu: Video Video Highlight Flash or SD Card and press “OK” button to confirm. It supports 3GP, FLV, MP4, MPG, VOB, AVI, RM, RMVB, WMV and MOV formats. Use / of Navigation Pad to highlight desired file or press Page Jump Buttons to turn pages if available. - Page 21 Main Menu: Video to pause /resume playback. Press / of Navigation Pad to skip 1. Press to previous/next video file. Press and hold / of Navigation Pad to rewind/ go forward quickly. Press / of Navigation Pad to adjust volume level. 2.
-
Page 22: Photo
Main Menu: Photo Photo The device supports only the following picture formats: JPEG, GIF, BMP and PNG. All other file formats will not be displayed on purpose. Press Navigation Pad to select Flash or SD Card and press “OK” button to confirm. - Page 23 Main Menu: Photo During picture playback, press to set a slide show. Select <Slide> to start the picture slideshow and click “OK” button. Use Navigation Pad to choose available time options between pictures. Options are 5, 10, 20 sec and “Turn Off”. When chosen, click “OK”...
-
Page 24: Explorer
Main Menu: Explorer Explorer Select file of Flash or SD Card and Press “OK” button to enter. All files in flash or SD Card are in the list. Use Navigation Pad to select the desired file or press Page Jump Buttons to turn pages. -
Page 25: User Manual
Main Menu: User Manual User Manual Included with the device are the Quick Start Guide and this PDF-format User Manual. This PDF-format User Manual can be browsed on both your computer and the device. Double click on the drive letter of the device, and then select the User Manual to start Adobe Reader and open the User Manual. - Page 26 Main Menu: User Manual Item Description To Page Page fits screen size. (Default Settings) To Width Page fits width of window. To height Page fits height of window. The scale switches in S size. The scale switches in M size. The scale switches in L size.
-
Page 27: Settings
Main Menu: Settings Settings From the main menu, press Navigation Pad to select Settings, and then press “OK” button to enter Settings menu. Use Navigation Pad to select desired item and press “OK” button to enter settings. In the Settings menu, you can configure the following settings. ... - Page 28 Main Menu: Settings Language Available options are “English”, “French”, “German”, “Russian”, “Polish”, “Italian”, “Czech”, “Slovak”, “Greek”, “Serbian”, “Bulgarian”, “Romanian”, “Estonian”, “Lithuanian”, “Latvian”, “Hungarian” and “Spanish”. System Information Display the technical information of the device. Auto Shut Down Time Turn off the device to minimize the power consumption of the battery.
- Page 29 Main Menu: Settings Note: The following format for the time and date settings Time Setting: Hour Minute Date setting: Year Month Date Calendar Display the calendar. Press Navigation Pad to select the day. Press Page Jump Buttons to skip to particular year. ...
-
Page 30: Creating An Adobe Account
Importing Content Authorizing PC and Reader The Reader supports USB Mass Storage Device function. To import contents (e-books, video, audio, photo, etc) into the reader, connect the reader to PC via supplied USB cable. Upon successful connection to PC, the reader will enter USB mode and all the operations will be halted. -
Page 31: Installing Adobe Digital Editions (Ade)
Importing Content Installing Adobe Digital Editions (ADE) For first time use you will need to get a free Adobe ID from Adobe website. Click on the [get an Adobe ID online] link as illustrated: 7’ eBook Reader... - Page 32 Importing Content Installing Adobe Digital Editions (ADE) Enter your e-mail address and complete the online form as instructed. 7’ eBook Reader...
-
Page 33: Authorizing Pc And Reader
Importing and Transferring Content Authorizing PC and Reader Upon registration, return to the ADE window. Enter the username and password to activate your Adobe account. After activation, connect the Reader to PC. ADE will detect the Reader and you are prompted to authorize the device. -
Page 34: Transferring Drm E-Books To Reader
Importing and Transferring Content Transferring DRM e-books to Reader From ADE menu, click on [All Items] in the left hand column. Items in [My Digital Editions] will be listed down in the right window. Select the desired item(s) to be transferred. ... -
Page 35: Product Specifications
Built-in Lithium Battery, 3500 mAh Dimensions 195 mm x 145 mm x 13 mm (L x W x H) Weight 375 g Technical Support and Warranty Information Please refer to www.prestigio.com for technical support and included warranty card for warranty information. 7’ eBook Reader... -
Page 36: Copyright And Trademark Notice
MP3 audio coding technology and patents are licensed from Egoman Ltd. Prestigio Libretto PER307 contains Adobe® Reader® Mobile software under license from Adobe Systems Incorporated, Copyright © 1995-2009 Adobe Systems Incorporated. All rights reserved. Adobe and Reader are trademarks of Adobe Systems Incorporated.
