- Page 1 PRESTIGIO NOBILE e-Book Reader PER3072B www.prestigio.com...
-
Page 2: Table Of Contents
Table of Contents Disclaimer Introduction Package Content Getting Started Charging the Reader Power On/Off, Reset Device, Insert MicroSD Main Menu History Books Music Video Photo Explorer Game Settings Product Specifications Technical Support and Warranty Information Copyright and Trademark Notice 7’ eBook Reader EN-2... -
Page 3: Disclaimer
Introduction Prestigio Nobile PER3072B is an e-book reader with full color TFT display screen 19 cm (7”) diagonal and resolution of 800*600. PER3072B supports e-books encrypted with FB2, HTML, etc. -
Page 4: Package Content
Package Content E-book Reader USB cable Leather Cover User guide in multiple languages International warranty card 7’ eBook Reader EN-4... -
Page 5: Getting Started
Getting Started Previous Page Skip to previous page, Volume down Next Page Skip to next page, Volume up Menu Button Enter the menu options Zoom Button Zoom in/out contents on screen Navigation Pad Navigate through all options “OK”; Play/ Pause “OK”... -
Page 6: Charging The Reader
Getting Started Charging the Reader You need to charge the Reader prior to using it for the first time or when battery power is low. Note: It’s recommended to charge the battery for 4 hours before the first time use. Normally it takes approximately 3~4 hours to fully charge the device. Recharge the device as soon as possible when the battery is in low-power level shown as icon appears once the battery is fully charged. -
Page 7: Power On/Off, Reset Device, Insert Microsd
Getting Started Power Reader On and Off • Press and hold the [Power] button for 5-6 seconds to turn on Reader - it will automatically enter the main menu on Home screen after the start-up screen. • It may take a few moments for reader to turn on and load the content. •... -
Page 8: Main Menu
Main Menu The main menu includes History, Book, Music, Video, Photo, Explorer, User Manual, and Settings. Use the Navigation Pad to highlight the desired mode and press “OK” button to confirm. Press to return to previous option. 7’ eBook Reader EN-8... -
Page 9: History
Main Menu: History History Files viewed in the past will be displayed on the screen. Press Navigation Pad to navigate to History icon and press “OK” button to enter previously opened files list. At the files list, press to pop up the option menu. - Page 10 Main Menu: History • Use the Navigation Pad to select the desired files or press Page Jump Buttons to turn pages if available. Press “OK” button to open file or press to exit the mode. • During text playback, press Page Jump Buttons or Navigation Pad to turn pages.
- Page 11 Main Menu: History Item Description Go To Page Press the Navigation Pad to select desired page. Press “OK” button to confirm or press to cancel. Save bookmark Press “OK” button to save the address of the current page. 5 items are available. Open bookmark Highlight the item and press “OK”...
-
Page 12: Books
Main Menu: Books Books Nobile PER3072B supports 6 kinds of e-book formats, including PDF, EPUB, FB2, PDB(PALM DOC), TXT, HTML. Press Confirm Button to enter Book mode. Press to select the desired sorting method (By Thumbnail /File Name / Title / Author). Highlight the item and press “OK”... - Page 13 Main Menu: Books of Navigation Pad to select the desired file in the books list or press Page Jump Buttons to turn pages if available. Highlight the desired file and press “OK” button to open file. During text playback, press Page Jump Buttons or Navigation Pad to turn pages.
- Page 14 Main Menu: Books Item Description Catalog The book index information is displayed. Highlight desired item and press “OK” button to confirm. NOTE: The Catalog function is only available with files in PDF and EPUB formats with index information. Note: Please refer to History part for more detailed instructions of other items. Reading books while playing a track.
-
Page 15: Music
Main Menu: Music Music Use the Navigation Pad to select the icon and press “OK” button to enter the mode. The music list will be displayed. It supports WMA, AAC, WAV, OGG, FLAC and MP3 files’ formats only. Note: Music files saved on micro SD card are also displayed in the list. Item Description Music play/... - Page 16 Main Menu: Music Highlight Music/Resume Play to enter current playback screen. To play the lists of All Music, Artist, Album, My favorites, Genre and Directories List, press Navigation Pad to select desired track or press Page Jump Buttons to turn pages if available, and then press “OK” button to enter playback screen.
- Page 17 Main Menu: Music Press to pop up the options menu. Highlight Delete/Delete All and press “OK” button to delete current music file or all files in My Favorites. 7’ eBook Reader EN-17...
- Page 18 Main Menu: Music On the playback screen, the following operations can be performed. 1. Press of Navigation Pad to adjust volume level. Press of Navigation Pad to skip to previous/next track. Press to pause /resume playback. Press and hold of Navigation Pad to rewind/go forward. Press exit playback screen.
- Page 19 Main Menu: Music 2. Press to enter Music Settings as follows. Use Navigation Pad to highlight item and press “OK” button (repeatedly) to confirm. Press to exit settings. Item Description Repeat Settings Play modes’ settings. Play Settings Play orders’ settings. Sound Effect Equalizer settings.
- Page 20 Main Menu: Music It is possible to read books (or view pictures) while playing a track. During music playback, press to enter background music mode, in which you can use the device with playing music. Press to display play bar and press it again to pause /resume playback any time.
-
Page 21: Video
Main Menu: Video Video Highlight Flash or SD Card and press “OK” button to confirm. It supports 3GP, FLV, MP4, MPG, VOB, AVI, RM, RMVB, WMV and MOV formats. of Navigation Pad to highlight desired file or press Page Jump Buttons to turn pages if available. - Page 22 Main Menu: Video 1. Press to pause /resume playback. Press of Navigation Pad to skip to previous/next video file. Press and hold of Navigation Pad to rewind/ go forward quickly. Press of Navigation Pad to adjust volume level. 2. Fast forward/rewind speed varies, depending on the length of the video. 3.
-
Page 23: Photo
Main Menu: Photo Photo The device supports only the following picture formats: JPEG, GIF, BMP and PNG. All other file formats will not be displayed on purpose. Press Navigation Pad to select Flash or SD Card and press “OK” button to confirm. - Page 24 Main Menu: Photo During picture playback, press set a slide show. Select <Slide Show> to start the picture slideshow and click “OK” button. Use Navigation Pad to choose available time options between pictures. Options are 5, 10, 20 sec and “Turn Off”. When chosen, click “OK”...
-
Page 25: Explorer
Main Menu: Explorer Explorer Select file of Flash or SD Card and Press “OK” button to enter. All files in flash or SD Card are in the list. Use Navigation Pad to select the desired file or press Page Jump Buttons to turn pages. -
Page 26: Game
Main Menu: Game Game Use the Navigation Pad to select the icon and press the “OK” button to enter the mode. There are three games listed. Highlight the desired game and press the “OK” button to enter. 1. Sokoban There are 50 levels in total. Press Page Up/Page Down button to change the level;... -
Page 27: Settings
Main Menu: Settings Settings From the main menu, press Navigation Pad to select Settings, and then press “OK” button to enter Settings menu. Use Navigation Pad to select desired item and press “OK” button to enter settings. In the Settings menu, you can configure the following settings. Auto Shut Down Time Turn off the device to minimize the power consumption of the battery. - Page 28 Main Menu: Settings Display Settings Backlight Time To set backlight display time. Brightness To adjust brightness. Language Available options are “English”, “French”, “German”, “Russian”, “Polish”, “Italian”, “Czech”, “Slovak”, “Greek”, “Serbian”, “Bulgarian”, “Romanian”, “Estonian”, “Lithuanian”, “Latvian”, “Hungarian”, “Spanish”, “Slovenian” and “Croatian”. System settings Restore Defaults Highlight Yes and press “OK”...
- Page 29 Main Menu: Settings Note: The following is the format for the time and date settings. Time Setting: Hour Minute Date setting: Year Month Date User Manual Included with the device are the Quick Start Guide and this PDF-format User Manual. This PDF-format User Manual can be browsed on both your computer and the device.
- Page 30 Main Menu: Settings Item Description To Page Page fits screen size. (Default Settings) To Width Page fits width of window. To height Page fits height of window. The scale switches in S size. The scale switches in M size. The scale switches in L size. Selection To select desired section of page.
-
Page 31: Product Specifications
Dimensions 195 mm x 145 mm x 13 mm (L x W x H) Weight 375 g Technical Support and Warranty Information Please refer to www.prestigio.com for technical support and included warranty card for warranty information. 7’ eBook Reader EN-31... -
Page 32: Copyright And Trademark Notice
The "Prestigio" trademark and “Prestigio” logos are owned by Prestigio Plaza Limited. Other trademarks are property of their lawful owners. All pre-loaded software components and individual programs contained in the Product are licensed and not sold.
