Instruction Manual
2x2/4/8 High Resolution Matrix VGA
Video Switch
ST222MX
ST222MXGB
ST224MX
ST228MX
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 02/23/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com ST222MX
Summary of Contents for StarTech.com ST222MX
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 02/23/2012...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Features ................................ 1 Package Contents ............................. 1 Installation ....................2 Operation for Cascade ..........................2 Input/Output Signal Specifications ....................3 Specifications ..................4 Technical Support ..................5 Warranty Information ................5 Instruction Manual... -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com Dual Input VGA Matrix Video Splitter for your desktop computer or workstation. The ST222MX, ST224MX and ST228MX offer the highest quality video on multiple monitor hookups. The Matrix Video Splitter allows you to connect two, four or eight monitors to two or more computers and switch the video signals to any desired monitor. -
Page 5: Installation
Installation 1. Turn off the power to the computers and monitors. 2. Connect a HD-15 video extension cable between the VGA cards of the computers and the “Video In” ports on the back of the Matrix Video splitter. 3. Connect the HD-15 video extension cables from the monitors and plug them into the “Video Out 1”... -
Page 6: Input/Output Signal Specifications
Input/Output Signal Specifications Pin# Signal Red Video Green Video Blue Video ID2* Ground Analog Ground Analog Ground Analog Ground Ground ID0* ID1* Horizontal Sync Vertical Sync ID3* *For video out port 1 and 2 Instruction Manual... -
Page 7: Specifications
Specifications Max Resolution 1920 x 1440 (60Mhz) Pixel Frequency 250 Mhz Cable Distance (Device to Monitor) 65m (213’) Maximum Signal Type VGA, SVGA, XGA, Multisync Power Adapter (Min) AC 7.5V (800mA) Housing Metal Standards DVI 1.0 by DDWG Safety Standards FCC and CE Mark Instruction Manual... -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 9 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
