4 in 1 Crib
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
Conforms to
ASTM F1169-10a Full
Size Crib & F1821
Safety Standards
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
January 18, 2014, 24684 R3
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
___________
Lot:
___________
Date:
___________
When contacting Delta Consumer Care please reference
the above information. Before contacting Delta Consumer
Care please ensure that the information above matches the
information found on the label on the Crib End bottom rail,
please reference the information found on the product
when contacting Delta Consumer Care.
A
REV
©2014 DELTA ENTERPRISE CORP.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6792 and is the answer not in the manual?

Questions and answers

Related Manuals for Delta 6792

Summary of Contents for Delta 6792

  • Page 1 ___________ New York, NY 10001 Tele.212-645-9033 When contacting Delta Consumer Care please reference the above information. Before contacting Delta Consumer Care please ensure that the information above matches the information found on the label on the Crib End bottom rail,...
  • Page 2 Securely tighten loose bolts and other fasteners. Do not use crib if any parts are missing, damaged or broken. Contact Delta Children's Products for replacement parts and instructional literature if needed. Do not substitute parts.

  • Page 3: Notes On Care And Maintenance

    - Do not scratch or chip the finish. - Inspect the product periodically, contact Delta Children's Products for replacement parts or questions. - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a damp, cold basement.
  • Page 4 HARDWARE SYSTEM - REVIEW BEFORE ASSEMBLY AA. M6 x 50 mm Bolt x 2 HH. Plastic Clamp x 2 1. Insert the Dowels in the Rail into the holes in the Post. 2.Insert the Bolt into the slot. Turn clockwise with fingers or the Allen wrench provided.
  • Page 5 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. HARDWARE KIT PART #24683. A. SIDE x 2 D. Left Post x 2 Part #24674 B. Left Crib End x 1 Part #24677 Part# 24675 E. Right Post x 2 PRODUCT LABEL Part #24678 C.

  • Page 6: Section 1: Crib Assembly

    Section 1: Crib Assembly Step 1 Parts and tools required to complete step. B. Left Crib End C. Right Crib End D. Left Post x 2 M4 Allen Wrench Supplied BB. M6 x 45 mm Bolt x 12 WARNING LABEL PRODUCT LABEL EE.

  • Page 7: Warning Label

    Section 1: Crib Assembly Step 2 Parts and tools required to complete step. M4 Allen Wrench Supplied EE. Φ3 x 32 mm Metal Pin x 4 Right End Left End From Step 1 A. SIDE x1 BB. M6 x 45 mm Bolt x 6 Attach (1) Crib Side (Part A) to the assemblies from Step 1 using (6)M6x45 Bolts (Part BB) and (4) Metal Pins (Part EE).
  • Page 8 Section 1: Crib Assembly Step 3 Parts and tools required to complete step. M4 Allen Wrench Supplied L. Mattress Support x 1 From Step 2 DD. M6 x 18 mm Bolt x 4 Attach the Mattress Support (Part L) in all corners using (1) M6X18 mm Bolt (Part DD) in each corner. Tighten with the M4 Allen Wrench.
  • Page 9 Section 1: Crib Assembly Step 4 Parts and tools required to complete step. M4 Allen Wrench Supplied EE. Φ3 x 32 mm Metal Pin x 4 A. SIDE x1 From Step 3 BB. M6 x 45 mm Bolt x 6 Attach Crib side (Part A) to the assembly from Step 3 using(4) Φ3 x 32mm Metal Pins(Part EE) and (6) M6x45mm Bolts (Part BB).
  • Page 10 Section 1: Crib Assembly Step 5A Parts and tools required to complete step. F. Left Base Rail x2 EE. Φ3 x 32 mm Metal Pin x 4 G. Right Base Rail x2 FF. Cam Bolt x 4 From Step 4 M4 Allen Wrench Supplied PHILLIPS SCREWDRIVER...
  • Page 11 Section 1: Crib Assembly Step 5B CC. M6 x 30 mm Bolt x 4 H. Center Base Rail x1 From Step 5A M4 Allen Wrench Supplied Attach Center Base Rail (Part H) Using (4) M6 x 30mm Bolt (Part CC). Tighten with M4 Hex Wrench.
  • Page 12 Ne w York, NY 10001 Tele.212-645-9033 FACTORY When contacting Delta Consumer Care please reference the above information. Before contacting Delta Consumer Care please ensure that the information above matches the information found on the label on the Crib End bottom rail,...

  • Page 13: Section 2: Toddler Bed Conversion

    Section 2: Toddler Bed Conversion Step 1 Parts and tools required to complete step. M4 Allen Wrench Supplied From Step 5B Remove the Base installed in Step 5 of Section 1. Remove the Side installed in Step 6 of Section 1. Gently pull ends to remove pins...
  • Page 14 Section 2: Toddler Bed Conversion Step 2 EE. Φ3 x 32 mm Metal Pin x 2 J. Conversion rail x1 AA. M6 x 50 mm Bolt x 2 From Section 2: M4 Allen Wrench HH. Plastic Clamp x 2 Step 1 Supplied Install Conversion Rail to the Crib Front Using (2) Metal Pins (Part EE), (2) M6 x 50mm Bolts (Part AA) and (2) Plastic Clamps (Part HH).
  • Page 15 Section 2: Toddler Bed Conversion Step 2 Repeat Step 5 from Section 1...
  • Page 16 Stabilizer bar must be used when converted to a toddler bed. A toddler bed guardrail is available for this crib. Please see your crib retailer, visit www.DeltaChildren.com or contact Delta Consumer Care for more information. This crib uses Delta Style # 0080 Guardrail.

  • Page 17: Section 3: Full Size Bed Conversion

    Section 3: Full Size Bed Conversion Step 1 Parts and tools required to complete step. M4 Allen Wrench Supplied You have the option to convert the crib to a full size bed. Simply follow steps in reverse order to disassemble the crib. Store any unused parts and hardware safely out of the reach of small children. See page 3.
  • Page 18 Section 3: Full Size Bed Conversion Step 2 Parts and tools required to complete step. D. Left Post x 2 M4 Allen Wrench Supplied BB. M6 x 45 mm Bolt x 12 E. Right Post x 2 A. SIDE x 2 EE.
  • Page 19 Attach Bed Frame to the Headboard (and Footboard) (From Section 3 Step 1) using M6 x 18mm Bolts (Part N). Follow all instructions supplied with the Bed Rails or Bed Frame. Note: Bed system is not included, see your furniture or mattress retailer. Contact Delta Chidren’s Products for information or with questions.

  • Page 20: Warranty
