Observing LED Activity

O P O
N AND OWERING FF
3. Ensure that the power source to which you have connected the chassis is
on.
4. Move the top power source (A) switch, located in the lower-right front of
the chassis, to the on position.
5. If you have connected to a second power source, move the lower power
source (B) switch, located in the lower right-front of the chassis, to the on
position.
Re ad Ma
nua l
be for e
act ua ting
but ton
Figure 6-1 Power On/Off Switches
Modules have power and fault LEDs to indicate operating status. When you
power on the Cuda 12000, the LEDs on the modules illuminate as each
module begins an initialization process that includes diagnostics and the
loading of operational code, as described in "Understanding the Initialization
Process," next.
BAC_28B
