Summary of Contents for Aritech CS-175-275-575 Series
- Page 1 CS-175-275-575 Series LED User Guide...
- Page 2 PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point. Aritech is an Interlogix company © 2001 Interlogix B.V. All rights reserved. Interlogix B.V. grants the right to reprint this manual for internal use only.
-
Page 3: Table Of Contents
........Unbypassing (including) zones ..... . . CS-175-275-575 Series • LED User Guide... -
Page 4: Led Keypad
Stay: Press to arm part of the Star: Used to enable certain system when in the premises. functions. Away: Press to arm complete Chime: Press to turn the chime on system when leaving the premises. and off. CS-175-275-575 Series • LED User Guide... - Page 5 Hash key. Used to access modules and locations. Stay. This function key part arms your system. Pressing it disarms all interior zones but leaves the perimeter protected. Star. Used to access tasks and enter data. CS-175-275-575 Series • LED User Guide...
-
Page 6: Turning On Your System
See section “Bypassing and Unbypassing”. User Action: Type your user code to turn on the system. LED Display: The armed LED illuminates. You can now leave the premises. CS-175-275-575 Series • LED User Guide... -
Page 7: Turning On Your System In Stay G Mode
Turning on your system in Stay g mode Using the function keys. (This feature must be programmed by the installer.) User Action: Press G. LED Display: The armed LED will illuminate. CS-175-275-575 Series • LED User Guide... -
Page 8: Turning On Your System In Away H Mode
Turning on your system in Away h mode Using the function keys. (This feature must be programmed by the installer.) User Action: Press H. LED Display: The armed LED will illuminate. CS-175-275-575 Series • LED User Guide... -
Page 9: Turning Off Your System
The armed (red) LED goes off (if programmed to be on), zone LED(s) go off and the keypad stops buzzing. The system is now turned off. If there are open zones, the zone LEDs will flash. CS-175-275-575 Series • LED User Guide... -
Page 10: Bypassing (Excluding) Zones
Press the zone number(s) you would like to exclude. User Action: Press I. LED Display: Zone LEDs stop flashing and ready LED illuminates. User Action: Type your user code to turn on the system. CS-175-275-575 Series • LED User Guide... -
Page 11: Unbypassing (Including) Zones
Press the zone number(s) you would like to include. LED Display: The corresponding zone LED(s) go off indicating the zone has been unbypassed. User Action: Press I. User Action: Type your code to turn on the system. CS-175-275-575 Series • LED User Guide... -
Page 12: Changing User Codes
LED Display: The OK LED is STEADY. User Action: Type the new user code, for example 6543 for a 4-digit user code, 654321 for a 6-digit user code. CS-175-275-575 Series • LED User Guide... - Page 13 Changing user codes (continued) LED Display: The OK LED flashes. User Action: Press # to exit the User Code Programming Mode. CS-175-275-575 Series • LED User Guide...
-
Page 14: Deleting User Codes
S or six times (for a 6-digit user code) to delete a user code. LED Display: The OK LED flashes. User Action: Press # to exit the User Code Programming Mode. CS-175-275-575 Series • LED User Guide... -
Page 15: Resetting Fire Detectors
User Action: Press * 7 (Fire detector reset). Wait 10 seconds while $ è S the fire detectors are reset. LED Display: The fire LED will go off if all detectors have been reset. CS-175-275-575 Series • LED User Guide... -
Page 16: Setting The Keypad Tone
Use up/down arrow to adjust the keypad tone. j increases the pitch of the tone. k decreases the pitch of the tone. LED Display: The Service LED flashes. User Action: Use # to accept the tone you like. CS-175-275-575 Series • LED User Guide... -
Page 17: Service Messages Display On The Led Keypad
2 Siren Trouble 3 Box Tamper 4 Expander Power 5 Expander Low Battery 6 Expander Box Tamper 7 Expander Trouble 8 Ground Fault Press # to return to the 1 of 8 service LEDs. CS-175-275-575 Series • LED User Guide... - Page 18 LED(s) will illuminate showing communicate between your system and the which zones have a trouble condition. Press # central station. to return to the 1 of 8 service LEDs. CS-175-275-575 Series • LED User Guide...
-
Page 19: Glossary Of Terms
Fire LED A steady fire LED means a fire zone has been activated. Partitioned system A system divided into multiple areas. A rapidly flashing fire LED means that a fire zone is in a Each area can be controlled by seperate users. trouble condition. CS-175-275-575 Series • LED User Guide... - Page 20 Glossary of terms (continued) Perimeter The outer edge of the protected area. Tamper If the security system is interfered with, a tamper is recorded. You should contact your installer. Power LED When lit, the system is connected to the mains power.
