  • Page 1 CS-175-275-575 Series LCD User Guide...
  • Page 2 PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point. Aritech is an Interlogix company. © 2001 Interlogix B.V. All rights reserved. Interlogix B.V. grants the right to reprint this manual for internal use only.
  • Page 3: Table Of Contents

    Contents LCD keypad ............4 Setting the keypad tone ........16 Preparing your system .......... 6 Setting the system clock ........17 Turning on your system ......... 7 Viewing zone status ........... 19 Turning off your system ........8 Viewing alarm memory ........20 Turning off your system in case of alarm ....
  • Page 4: Lcd Keypad

    LCD keypad Power (green): When lit, the Stay: Press to arm perimeter system is connected to the mains protection when on the premises. power. Ready (green): When lit, the Away: Press to arm complete system is ready to be turned on. system when leaving the premises.
  • Page 5 LCD keypad Power (green). The power light is on if the system is Away. Press to arm all zones before leaving. connected to the mains and if the battery is okay. The power light will flash if the system has a low battery condition or when the battery is not connected.
  • Page 6: Preparing Your System

    Preparing your system System Not Ready LCD Message: Your system is NOT ready to be turned on, doors or windows might be open. For help, press User Action: Use the up/down arrow. X Fault X Bypass LCD Message: Zone information. Zone X Zone X User Action:...
  • Page 7: Turning On Your System

    Turning on your system OPTION 1: Using the function keys (This feature must be programmed by the installer.) System Ready LCD Message: Your system is ready to be turned on. Type code to arm User Action: For stay mode, push the stay button, for away mode push the away button.
  • Page 8: Turning Off Your System

    Turning off your system System Armed LCD Message: Your system is turned on. All Zones Secure User Action: Type your user code to turn off your system. System Ready LCD Message: Your system is ready to be turned on. Type code to arm CS-175-275-575 Series •...
  • Page 9: Turning Off Your System In Case Of Alarm

    Turning off your system in case of alarm ALARM Zone X LCD Message: An alarm has occurred in zone X. User Action: Type your user code to turn off your system. X Alarm Mem. LCD Message: The last alarm is shown on the LCD message Zone X for verification.
  • Page 10: Bypassing (Excluding) One Or More Zones

    Bypassing (excluding) one or more zones System Not Ready LCD Message: Your system is NOT ready to be turned on. For help, press jk S User Action: Use the up/down arrow. 1 Okay LCD Message: Shows the state of the first zone. Zone 1 jk S User Action:...
  • Page 11 Bypassing (excluding) one or more zones (continued) System Ready LCD Message: Your system is ready to be turned on. Type code to arm User Action: Type your user code to turn on the system. System Armed LCD Message: Your system is turned on, Zone(s) Bypassed but zones are bypassed (excluded) and not protected.
  • Page 12: Life Safety Functions

    Life safety functions You must press and hold the keys for 2 seconds to activate these functions! FIRE & + “ S User action: Press keys 1 and 3 together for two seconds. FIRE. A fire alarm is started and a message is sent to the central station.
  • Page 13: Resetting Fire Detectors

    Resetting fire detectors ALARM LCD Message: Alarm message after a fire alarm. fire alarm User Action: Type your user code to turn the system off. 8 Alarm Mem. fire alarm User Action: Press # System Ready LCD Message: Your system is turned off, and the fire detector has been activated.
  • Page 14: Changing User Codes

    Changing user codes System Ready LCD Message: The system is ready to be turned on. Type code to arm $( S User Action: Press * 5. Please Enter LCD Message: The system asks for a master user code. Your Code User Action: Enter your master user code.
  • Page 15: Deleting User Codes

    Deleting user codes System Ready LCD Message: The system is ready to be turned on. Type code to arm $( S User Action: Press * 5. Please Enter LCD Message: The system asks for a master user code. Your Code User Action: Enter your master user code.
  • Page 16: Setting The Keypad Tone

    Setting the keypad tone System Ready LCD Message: The system is ready for arming. Type code to arm $ à S User Action: Press * 0. Raise tone LCD Message: You will hear the current tone. Lower tone User Action: Use up/down arrow to adjust the keypad tone.
  • Page 17: Setting The System Clock

    Setting the system clock System Ready LCD Message: The system is ready to be turned on. Type code to arm $çèS User Action: Press * 97. Please Enter LCD Message: The system asks for a user code. Your Code User Action: Enter your user code.
  • Page 18 Setting the system clock (continued) Wed 16:09 LCD Message: Current date and time are shown. 29 November 01 User Action: Use the up/down arrow to change the hour,then minutes, day of the week, day of the month, month and year. User Action: After you have the correct value, press * to move to the next item in the list.
  • Page 19: Viewing Zone Status

    Viewing zone status System Ready LCD Message: The system is ready to be turned on. Type code to arm $ j S User Action: Press * and up arrow. 1 Okay LCD Message: The first zone is shown. Living room User Action: Use either up or down arrow to scroll.
  • Page 20: Viewing Alarm Memory

    Viewing alarm memory System Ready LCD Message: The system is ready to be turned on. Type code to arm $ “ S User Action: Press * 3. 3 Alarm Mem. LCD Message: The first alarm in memory is shown. Zone 3 User Action: Use either up or down arrow to scroll.
  • Page 21: Reading The Event Log

    Reading the event log System Ready LCD Message: The system is ready to be turned on. Type code to arm $ç à S User Action: Press * 90. Please Enter LCD Message: The system asks for a user code. Your Code User Action: Enter your user code.
  • Page 22: Adjusting View/Brightness Of The Lcd (Text Display)

    Adjusting viewing angle/brightness of the LCD (text display) System Ready LCD Message: The system is ready to be turned on. Type code to arm $ç & S User Action: Press * 91. Please Enter LCD Message: The system asks for a user code. Your Code User Action: Enter your user code.
  • Page 23: Service Messages Display

    Service messages display Service Required LCD Message: Please contact your installer. Type *2 for help $ é S User Action: Press * 2 to see what is causing the problem. Expansion LCD Message: This message represents a tamper box tamper of an expansion box or a keypad.
  • Page 24 Service messages display (continued) A short circuit of a control’s power A short to ground has been Control Control supply has occurred. detected on a control circuit. Over-current Ground fault Open circuit has occurred Your system has lost total power Control Control on the bell or siren circuit.
  • Page 25 Service messages display (continued) An auxiliary reporting device has Open circuit has occurred on the Expansion Expansion failed to communicate. bell or siren circuit of the expander. Aux. comm. fail Siren trouble The mains power to an expansion Expansion Zone Tamper, A zone is tampered.
  • Page 26: Glossary Of Terms

    Glossary of terms Armed The security system is turned on. Forced arming An option that allows the system to be armed with one or more zones open. When the system is ready Away Mode Turns on all of the security system. to be force armed, the ready LED flashes.
  • Page 27 Glossary of terms (continued) Power LED When lit, the system is connected to the mains power. Ready LED When lit, the system is ready to be turned on. Stay Mode Turns on the perimeter protection part of the security system. Tamper If the security system is interfered with, a tamper is recorded.
