Introduction

The SATDOCKCRH combines the convenience of a SATA docking station with a 13-in-1 card
reader and 2-port USB hub, and can be connected to a host computer through either USB or
eSATA.
Providing immediate access to SATA hard drive contents, (by simply inserting the HDD into
the SATA dock), SATDOCKCRH lets you copy the contents between your memory cards, flash
drives and bare SATA hard drives all from one centrally connected device when connected to a
computer. The HDD docking station supports data transfer speeds of up to 3 Gbps (using eSATA)
and 480Mbps (using USB 2.0) between host and dock - ensuring effortless data dumps, backups
and hassle-free file transfers.

Packaging Contents

• 1 x SATDOCKCRH hard drive dock
• 1 x eSATA cable
• 1 x USB cable (A-B)
• 1 x Power Adapter
• 1 x Instruction Manual

System Requirements

• USB and/or eSATA enabled computer system
• Windows 2000/ XP(32/64bit)/ Server 2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ Server 2008
R2, Linux, and MAC OS X and up
