GLOBE
Manuale di installazione
I
e manutenzione per porte
basculanti a molle e
sezionali.
Installation and maintenance
GB
manual for spring balanced
up and over door and
sectional overhead doors.
Manuel d'installation et
F
d'entretien pour portes
basculantes a ressort et
sectionneles.
Montage und
D
Wartungsanleitung für
Garagentorantriebe.
Manual de instalaciòn
E
y mantenimiento para
puertas basculante de
resortes y seccionales.
Manual de instalação e
P
manutenção para portas
basculantes a molas e
seccionadas.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DITEC GLOBE
Summary of Contents for DITEC GLOBE
- Page 1 Manual de instalação e manutenção para portas basculantes a molas e seccionadas. DITEC S.p.A. Via Mons. Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY Tel. +39 02 963911 - Fax +39 02 9650314 www.ditec.it - ditec@ditecva.com...
- Page 2 Fig. 1 Fig. 2 Fig. 3 GLOBE - IP1839...
- Page 3 Stringere! Attenzione alle mani! Tighten! Pay attention to hands! Fig. 4 GLOBE - IP1839...
- Page 4 Fig. 5a Fig. 5b Fig. 5c 3000 GLOBEGF - GLOBEGA Fig. 5d Fig. 5e Fig. 5f 1÷2 mm Fig. 6 GLOBE - IP1839...
- Page 5 10÷100 min. 680 Fig. 7a GLOBE - IP1839...
- Page 6 20 GLOBEC min. 900 GLOBEC Fig. 7b GLOBE - IP1839...
- Page 7 1÷2 mm Fig. 7c Fig. 7d max. 200 20÷100 Fig. 8a Fig. 8b GLOBE - IP1839...
- Page 8 Fig. 8c Fig. 8d Fig. 9 GLOBESI Fig. 10a Fig. 10b Fig. 10c GLOBE - IP1839...
-
Page 9: Operating Instructions
Declares that the automatic system for spring balanced up and The motor manufacturer declines all responsibility in the event over doors and sectional overhead doors of the GLOBE series: of component parts being fitted that are not compatible with the - is manufactured to be incorporated into a machine or to be safe an correct operation. - Page 10 The given operating and performance features can only be gua- (fig. 5b) Fit the belt stop as shown in the illustration. ranteed with the use of DITEC accessories and safety devices. (fig. 5c) Fasten the two ends of the belt to the release pin by means of the couplings keeping to the pin direction 2.1 Standard installation references (fig.
-
Page 11: Electrical Connections
POWER ALARM Only GLOBE10 Motor 24V= 15 14 0 1 5 8 9 ATTENTION: Make a jumper all the N.C. contacts if not used. Use only DITEC accessories and safety devices. 4.1 Controls Control Function Description N.O. STEP-BY-STEP With DIP1=OFF the closure of the contact activates the sequence: open-stop-close-open. - Page 12 Obstacle thrust adjustment. The control panel is equipped with a safety device that stops the opening operation and stops and inverts the closing operation in the presence of an obstacle. With R1=MIN there is maximum obstacle sensitivity (minimum thrust). MAX=disabled With R1=MAX the detection function is deactivated (maximum thrust). GLOBE - IP1839...
- Page 13 Upon starting the LED flashes indicating the count tacts is open. of the operations which have been carried out: each quick flashing = 1000 operations each slow flashing = 10000 operations During radio transmitter enabling/storing phase. During radio transmission reception. GLOBE - IP1839...
- Page 14 Note: if the position of the door stops is changed or, more in general, after maintenance operations, interrupt and restore power (batteries included if these are fitted) to repeat the learning process. IMPORTANT: For the spare parts, refer to the spare parts list. GLOBE - IP1839...
-
Page 15: Troubleshooting
The radio remote control has a Radio transmission is hampered by metal Install the antenna outside. Replace the batteries low range and does not work frameworks and reinforced concrete walls. of the transmitters. with the automation in motion. GLOBE - IP1839... - Page 16 OPERATING INSTRUCTION UP AND OVER AND SECTIONAL OVERHEAD DOOR AUTOMATION GLOBE RELEASE INSTRUCTION Perform the lock and release operations with the motor stopped. Keep outside the range of action of the door. If released, the door could move in an independent manner.
