CROSS 5E-7E-7EH-8E
DITEC S.p.A.
Via Mons. Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
www.ditec.it - ditec@ditecva.com
IP1747 - rev. 2005-12-06
Manuale di installazione
I
e manutenzione per
automazioni per cancelli
scorrevoli.
Installation and
GB
maintenance manual for
sliding gates automatic
system.
Manuel d'installation
F
et d'entretien pour
automatisme pour portails
coulissants.
Montage und
D
Wartungshandbuch
für Schiebtore
Automatisierung.
Manual para la instalaciòn
E
y la manutenciòn para
automatización para
cancelas de corredera.
Manual de instalação
P
e manutenção para
portaõ corrediço sistema
automatico.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DITEC CROSS 5E-7E-7EH-8E
Summary of Contents for DITEC CROSS 5E-7E-7EH-8E
- Page 1 CROSS 5E-7E-7EH-8E IP1747 - rev. 2005-12-06 Manuale di installazione e manutenzione per automazioni per cancelli scorrevoli. Installation and maintenance manual for sliding gates automatic system. Manuel d’installation et d’entretien pour automatisme pour portails coulissants. Montage und Wartungshandbuch für Schiebtore Automatisierung.
- Page 2 2x1.5 mm² 4x0.5 mm² RX-4x0.5 mm² TX - 4x0.5 mm² Fig. 1 Fig. 2 Cross 5E - 7E - 8E Cross 7EH Fig. 3 CROSS5-7-8 - IP1747...
- Page 3 Istallazione fotocellule all’interno del motoriduttore / Installing the photocells inside the geared motor / Installation de photocellules dans le motoreducteur / Installation der photozellen im Getriebemotor / Instalacion de las fotocelulas en el interior del motorreductor. min 500 mm ~400 mm 3.5x9.5 Fig.
- Page 4 Good Working Methods and in For more information consult the “Technical Manual Guidelines” compliance with applicable regulations. available on Internet at the following address: www.ditec.it Before installing the product, carefully read the instructions. Bad installation could be hazardous.
- Page 5 To reduce impact force installation of safety devices at gate The given operating and performance features can only be guar- ends is recommended. anteed with the use of DITEC accessories and safety devices. 3.2 Base plate prearrangement 2.1 Standard installation references (fig. 1)
- Page 6 Lay a concrete foundation with buried anchoring brackets 3.3 Geared motor installation and the base plate, making sure that it is perfectly level and Release the gearmotor and remove the key. Loosen the smooth (see figure). three frontal screws and remove the casing. Note: if the cement area is already present you can use the Position the gearmotor onto the base plate.
-
Page 7: Chain Installation
3.5 Adjusting limit switch 3.7 Cross7EHTC installation (only for Cross7EH) Manually position the door wing completely open and fasten Disengage the gearmotor (see OPERATING INSTRUCTIONS). the limit switch brackets [L] onto the rack so that the lever Remove the pinion [14]. Fix the pinion-holding plate to the limit switch exceeds the bracket’s length by approximately gearmotor. -
Page 8: Electrical Connection
ELECTRICAL CONNECTION BATK7 [17] BATTERY KIT INSTALLATION (only Cross7EH) Electrical wiring and starting are shown in the installation manual of control panel E1-E1A (Cross5E-7E-8E) and 73RG The BATK7 battery kit permits to operate the gate even in case (Cross7EH). of mains power failure. 230 V cables (power supply, flashing light and external courtesy Note: when not in use, batteries are kept charged by means of light, if any) are to be positioned on the right of the electric control... - Page 9 All installation, maintenance and repair work must be documented and made available to the user. Installator: DITEC S.p.A. Via Mons. Banfi, 3 21042 Caronno Pertusella (VA) - ITALY Tel. +39 02 963911 - Fax +39 02 9650314 www.ditec.it - ditec@ditecva.com...
