IP1837 - rev. 2007-07-17
DITEC S.p.A.
Via Mons. Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
www.ditec.it - ditec@ditecva.com
KIT REX
Manuale di assemblaggio
I
per porte scorrevoli.
Assembly handbook for
GB
sliding doors.
Manuel pour l'assemblage
F
pour portes coulissantes.
Zusammenbauanleitung
D
für Schiebtürantrieb.
Manual de ensemblaje
E
para puertas correderas.
Manual de assemblagem
P
para portas deslizantes.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DITEC KREX1V
Summary of Contents for DITEC KREX1V
- Page 1 Zusammenbauanleitung für Schiebtürantrieb. Manual de ensemblaje para puertas correderas. Manual de assemblagem para portas deslizantes. DITEC S.p.A. Via Mons. Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY Tel. +39 02 963911 - Fax +39 02 9650314 www.ditec.it - ditec@ditecva.com...
- Page 2 CODE DESCRIZIONE DESCRIPTION DESCRIPTION KREX1V Componenti fissi 1 anta: 1-leaf fixed components Composants fixes 1 battant: Gruppo comando e trazione Control and traction unit Groupe commande et traction Gruppo rinvio cinghia Transmission unit Groupe renvoi courroie Gruppo carrello Carriage unit...
- Page 3 CODE DESCRIZIONE DESCRIPTION DESCRIPTION Accessori Accessories Accessoires 0KZ18REX Blocco di sicurezza Safety lock Blocage de sécurité avec déblocage LOKSBM Sblocco supplementare Supplementary release device Déblocage supplémentaire REXAB Antipanico a batterie Antipanic with battery Antipanique à batterie Spazzolini Brushes Brosses VSP14V25 Spazzolini di tenuta Sealing brushes Brosse d’étanchéité...
- Page 4 Fig. 1 KIT REX - IP1837...
- Page 5 REX-2 OPEN OPEN OPEN OPEN Gruppo carrello con attacco anta intelaiata - Carriage unit with framed wing attachment - Groupe chariot avec fixation vantail sur châssis - Laufwagengruppe mit Anschluß für Rahmenflügel - Gru- po carro con fijación hoja en el marco - Grupo carro com engate portinhola encaixilhada KIT REX - IP1837...
- Page 6 REX-2 Code Note 02REX20 2000 2980 02REX22 1040 2200 3180 02REX24 1140 2400 3380 02REX26 1240 2600 3580 02REX28 1340 2800 3780 02REX30 1440 3000 3980 02REX32 1540 3200 4180 02REX36 1740 3600 4580 02REX40 1940 1020 4000 4980 02REX44 2140 1120 4400...
- Page 7 REX-1 DX OPEN OPEN Gruppo carrello con attacco anta cristallo - Carriage unit with crystal wing attachment - Groupe cha- riot avec fixation vantail verre - Laufwagengruppe mit Anschluß für Ganzglasflügel - Grupo carro con fijación hoja cristal - Grupo carro com engate portinhola em cristal KIT REX - IP1837...
- Page 8 REX-1 DX Code Note 01REX14 1400 2440 (1)(2) 01REX16 1600 2640 01REX18 1800 1035 2840 01REX20 1015 2000 1135 3040 01REX22 1015 1115 2200 1235 3240 01REX24 1115 1215 2400 1335 3440 01REX26 1215 1315 2600 1435 3640 01REX28 1315 1415 2800 1535...
- Page 9 REX-1 SX OPEN OPEN Gruppo carrello con attacco anta cristallo - Carriage unit with crystal wing attachment - Groupe cha- riot avec fixation vantail verre - Laufwagengruppe mit Anschluß für Ganzglasflügel - Grupo carro con fijación hoja cristal - Grupo carro com engate portinhola em cristal KIT REX - IP1837...
- Page 10 REX-1 SX Code Note 01REX12 1200 1840 (1)(2) 01REX14 1400 2040 01REX16 1600 2340 01REX18 1800 2540 01REX20 1015 2000 2740 01REX22 1015 1115 2200 2940 01REX24 1115 1215 2400 3140 01REX26 1215 1315 2600 3340 01REX28 1315 1415 2800 3540 01REX30 1415...
- Page 11 230 V~ Lock 1CELA Fig. 2 KIT REX - IP1837...
- Page 12 Fig. 3 KIT REX - IP1837...
- Page 13 GENERAL SAFETY PRECAUTIONS Loosen the belt connection bracket. Cut the belt to measurement LB (see tables), thread the This assembling manual is intended for professionally belt LB between the motor pulley and the transmission unit competent personnel only. [2] and join it in correspondence with the belt connection The assembling, the electrical connections and the settings bracket (Note: cut off any excess length).
- Page 14 TESTING THE AUTOMATIC SYSTEM WITH 192C ELECTRONIC BOARD 3.1 Checking the dip-switches ACTION OUTCOME DIP1 = OFF - lock not powered with closed door - a command powers the lock throughout the opening manoe- uvre Warning: DIP1 must be set to OFF. DIP2 = OFF for REX2 and REX1-DX - variation of the opening direction DIP2 = ON for REX1-SX...
- Page 15 TESTING THE AUTOMATIC SYSTEM WITH EL16 ELECTRONIC BOARD 4.1 Checking the dip-switches ACTION OUTCOME DIP1 = OFF for REX2 and REX1-DX - changing the opening direction DIP1 = ON for REX1-SX DIP2 = ON for REX - automation type selection Warning: DIP2 must be set to ON DIP1 = ON - battery function, if present, in the event of blackout...
