Installation Guide
Elise3
Rear side
COM1/COM2
LAN1
LAN2
S900/S900
A-bus
LON
V+ Ext/GND Ext
In1/In2 and
Out1/Out2
Error
12-24 V DC
100-240 V AC
3.2

Label for IP Address/Host Name

To facilitate future support and access to the module, the module's IP address or Host
name can be printed on a blank label and attached to the module as shown in the figure
below.
The blank label is found on the back side of the Getting started and Safety document:
"Elise3 – EMBEDDED LINUX SERVER
Figure 2. Label for the IP address or Host name
12 April 2011 Ver. D
COM ports for connection of RS232 communication, see
Ports (RS232 Communication with External Equipment)
Not applicable for the Elise3 Lite version.
Modular jacks (RJ45) for connection of 10baseT or 100baseT Ethernet
TCP/IP network, see 4.4.2 Ethernet Ports
Currently not used (for future releases)
Modular jacks (RJ45) for connection of A-bus from System 900 with
modular system bus cabling, see
on page 15.
Not applicable for the Elise3 Lite version.
Screw connector for connection of A-bus from System 900 when
modular system bus cable is not used, see
System 900 on page 15.
Not applicable for the Elise3 Lite version.
Screw connector for connection of the LON bus, see
page 16.
Applicable for the Elise3 LON version only.
External 12 V power supply to provide galvanic isolation of the inputs
and outputs, see below.
Connects AUX Inputs and
AUX Outputs, see 4.4.6 Connection of AUX Inputs and AUX Outputs
on page 17.
Connector where an error relay output is available, see
Relay Output on page 16.
Connection for external backup battery/power supply, see
Voltage on page 14
Connection of supply voltage, see
INCLUDING SAFETY INSTRUCTIONS
Figure 2.
on page 15.
on page 15.
4.4.3 A-bus connection to System 900
4.4.3 A-bus connection to
4.4.4 LON Bus
4.4.5 Error
4.3 Supply Voltage on page 14
", included in the delivery.
TD 92679GB
4.4.1 COM
on
4.3 Supply
