- Page 1 Star Manufacturing Installation International Inc. Operating 10 Sunnen Drive Instructions St. Louis, MO 63143 Phone: (314) 781-2777 2M-Z6395 Rev. -- 10/18/02 Fax: (314) 781-3636 STAR-MAX PROPANE GAS GRIDDLE 8G-624MZ-LP, 8G-636MZ-LP, 8G-648MZ-LP 8G-624TZ-LP, 8G-636TZ-LP, 8G-648TZ-LP...
-
Page 2: Specifications
SPECIFICATIONS 8G-624MZ-LP Type: Manual Control 2 Controls, 40,000 BTU, 498 sq. in. (3213.4 sq cm) Grid Area, 3/4" (1.9 cm) Plate Thickness, Approximate Weight: Installed 165 lbs. (74.8 kg); Shipping 175 lbs. (79.4 kg) Dimensions: 24"W x 27 3/4"D x 13 1/2"H (61 cm W x 70.5 cm D x 34.3 cm H) -
Page 3: Safety Symbol
SAFETY SYMBOL This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 4: General Installation Data
GENERAL INSTALLATION DATA This appliance, its pressure regulator and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that CAUTION system at test pressures in excess of 1/2 PSIG (3.45KPA). This appliance and its pressure regulator This equipment is designed and sold for commercial must be isolated from the gas supply piping system by use only by personnel trained and experienced in its... - Page 5 EXHAUST CANOPY GAS PIPING It is essential that facilities be provided over the griddle Gas piping shall be of such size and so installed as to to carry off fumes and gases. However, the unit should provide a supply of gas sufficient to meet the full gas not be directly connected to a flue or stack.
-
Page 6: Lighting Instructions
BURNER OPERATION (MODELS 624MA, LIGHTING INSTRUCTIONS 636MA, and 648MA ONLY) When griddle is first lit, it will smoke until the To ignite burners, turn burner valve knob to "HI" preservation oils and impurities are burned off. position. Each burner is controlled by an individual 1. - Page 7 COOKING (MODELS 624TA, 636TA, 648TA, CAUTION 624TB, 636TB and 648TB ONLY) Set the thermostat dial knob to the temperature 1. Never use Pumice, griddle stones, or abrasives on desired. After a preheating period of 30 minutes, the the surface of chrome top unit. thermostat will automatically maintain the selected 2 Never strike griddle surface with sharp instrument temperature within 50°...
-
Page 9: Parts List
PARTS LIST 10/18/02 EFFECTIVE 8G-624TZ-LP STAR-MAX GAS GRIDDLE 24" THERMOSTATIC CONTROL MODEL Number Part Description Number Number Unit 2R-Z1273 KNOB-CONTROL G3-Z6338 FRONT PANEL 2A-Z0314 G3-GD0078 (624TZ) GRIDDLE PLATE ASSEMBLY G3-Y7046 GREASE DRAWER GRIDDLE G3-Y7047 SLIDE DRAWER G3-624008 BURNER ASSEMBLY G3-624233 (624TZ) MANIFOLD ASSEMBLY COMPLETE G3-GD0037 (624TZ) MANIFOLD ASSEMBLY COMPLETE... - Page 10 PARTS LIST 10/18/02 EFFECTIVE 8G-636TZ-LP & 8G-648TZ-LP STAR-MAX GAS GRIDDLE 36" AND 48" THERMOSTATIC CONTROL MODEL Number Part Description Number Number Unit 2R-Z1273 (636/648) KNOB-CONTROL G3-Z6340 (636) FRONT PANEL G3-Z6342 (648) FRONT PANEL 2A-Z0314 G3-GD0081 (636TZ) GRIDDLE PLATE ASSEMBLY G3-GD0084 (648TZ) GRIDDLE PLATE ASSEMBLY G3-Y7046 GREASE DRAWER GRIDDLE...
