FAAC 770 COMPACT User Manual

ENGLISH

EC DECLARATION OF CONFORMITY FOR MACHINES

Manufacturer: FAAC S.p.A.
Address: Via Benini, 1 - 40069 Zola Predosa BOLOGNA - ITALY
Declares that: 770 mod. operator
• is built to be integrated into a machine or to be assembled with other machinery to create a machine under the
provisions of Directive 98/37/EC;
• conforms to the essential safety requirements of the following EEC directives:
73/23/EEC and subsequent amendment 93/68/EEC.
89/336/EEC and subsequent amendment 92/31/EEC and 93/68/EEC
and also declares that it is prohibited to put into service the machinery until the machine in which it will be
integrated or of which it will become a component has been identified and declared as conforming to the
conditions of Directive 98/37/EC.
Bologna, 01 January 2005
1) ATTENTION! To ensure the safety of people, it is important that you read
all the following instructions. Incorrect installation or incorrect use of
the product could cause serious harm to people.
2) Carefully read the instructions before beginning to install the product.
3) Do not leave packing materials (plastic, polystyrene, etc.) within reach
of children as such materials are potential sources of danger.
4) Store these instructions for future reference.
5) This product was designed and built strictly for the use indicated in this
documentation. Any other use, not expressly indicated here, could
compromise the good condition/operation of the product and/or be a
source of danger.
6) FAAC declines all liability caused by improper use or use other than that
for which the automated system was intended.
7) Do not install the equipment in an explosive atmosphere: the presence
of inflammable gas or fumes is a serious danger to safety.
8) The mechanical parts must conform to the provisions of Standards EN
12604 and EN 12605.
For non-EU countries, to obtain an adequate level of safety, the Standards
mentioned above must be observed, in addition to national legal
regulations.
9) FAAC is not responsible for failure to observe Good Technique in the
construction of the closing elements to be motorised, or for any
deformation that may occur during use.
10) The installation must conform to Standards EN 12453 and EN 12445.
For non-EU countries, to obtain an adequate level of safety, the Standards
mentioned above must be observed, in addition to national legal
regulations.
11) Before attempting any job on the system, cut out electrical power .
12) The mains power supply of the automated system must be fitted with an
all-pole switch with contact opening distance of 3mm or greater. Use
of a 6A thermal breaker with all-pole circuit break is recommended.
(DIRECTIVE 98/37/EC)
The Managing Director
A. Bassi
WARNINGS FOR THE INSTALLER
GENERAL SAFETY OBLIGATIONS
13) Make sure that a differential switch with threshold of 0.03 A is fitted
14) Make sure that the earthing system is perfectly constructed, and
15) The safety devices (EN 12978 standard) protect any danger areas
16) Use of at least one indicator-light (e.g. FAACLIGHT ) is recommended
17) FAAC declines all liability as concerns safety and efficient operation
18) For maintenance, strictly use original parts by FAAC.
19) Do not in any way modify the components of the automated system.
20) The installer shall supply all information concerning manual operation
21) Do not allow children or adults to stay near the product while it is
22) Keep remote controls or other pulse generators away from children,
23) Transit through the leaves is allowed only when the gate is fully open.
24) The user must not attempt any kind of repair or direct action whatever
25) Maintenance: check at least every 6 months the efficiency of the
26) Anything not expressly specified in these instructions is not permitted.
6
upstream of the system.
connect metal parts of the means of the closure to it.
against mechanical movement Risks, such as crushing, dragging,
and shearing.
for every system, as well as a warning sign adequately secured to the
frame structure, in addition to the devices mentioned at point "15".
of the automated system, if system components not produced by
FAAC are used.
of the system in case of an emergency, and shall hand over to the
user the warnings handbook supplied with the product.
operating.
to prevent the automated system from being activated involuntarily.
and contact qualified personnel only.
system, particularly the efficiency of the safety devices (including,
where foreseen, the operator thrust force) and of the release devices.
ENGLISH
