Outdoor Unit
Step
5
Unfasten the left side
hooks, and then the
right side hook.
Remove the front panel.
104
Procedure
SiBE07-618_C
Points
Lift the front panel while
pushing the left side panel
inwards.
Lift the front panel and
unfasten the right side hook.
When reassembling, fit the
right side of the front panel
first.
Removal Procedure
