Daikin C-Series Service Manual page 4

Part 6 Service Diagnosis............................................................. 54
1. Caution for Diagnosis............................................................................55
2. Problem Symptoms and Measures .......................................................56
3. Service Check Function ........................................................................57
4. Troubleshooting ....................................................................................60
5. Check ....................................................................................................94
Part 7 Removal Procedure ........................................................ 101
1. Outdoor Unit........................................................................................102
iii
2.1 Remote Controller ..................................................................................45
2.2 AUTO · DRY · COOL · HEAT · FAN Operation ......................................46
2.3 POWERFUL Operation ..........................................................................48
2.4 OUTDOOR UNIT QUIET Operation.......................................................49
2.5 HOME LEAVE Operation .......................................................................50
2.6 TIMER Operation ...................................................................................52
1.1 Troubleshooting with LED ......................................................................55
4.1 Error Codes and Description ..................................................................60
4.2 Indoor Unit PCB Abnormality .................................................................61
4.3 Freeze-up Protection Control or Heating Peak-cut Control....................62
4.4 Fan Motor (AC motor) or Related Abnormality.......................................64
4.5 Thermistor or Related Abnormality (Indoor Unit)....................................65
4.6 Signal Transmission Error (between Indoor Unit and Outdoor Unit) ......66
4.7 Unspecified Voltage (between Indoor Unit and Outdoor Unit) ...............67
4.8 Outdoor Unit PCB Abnormality...............................................................68
4.9 OL Activation (Compressor Overload) ...................................................69
4.10 Compressor Lock ...................................................................................70
4.11 DC Fan Lock ..........................................................................................71
4.12 Input Overcurrent Detection ...................................................................72
4.13 Four Way Valve Abnormality..................................................................73
4.14 Discharge Pipe Temperature Control.....................................................75
4.15 High Pressure Control in Cooling ...........................................................76
4.16 Compressor System Sensor Abnormality ..............................................77
4.17 Position Sensor Abnormality ..................................................................78
4.18 CT or Related Abnormality .....................................................................80
4.19 Thermistor or Related Abnormality (Outdoor Unit).................................82
4.20 Electrical Box Temperature Rise............................................................84
4.21 Radiation Fin Temperature Rise ............................................................86
4.22 Output Overcurrent Detection ................................................................88
4.23 Refrigerant Shortage ..............................................................................90
4.24 Low-voltage Detection or Over-voltage Detection..................................92
4.25 Signal Transmission Error (on Outdoor Unit PCB).................................93
5.1 How to Check .........................................................................................94
1.1 Removal of Outer Panels .....................................................................102
1.2 Removal of Outdoor Fan / Fan Motor...................................................106
1.3 Removal of Electrical Box ....................................................................110
1.4 Removal of PCB...................................................................................115
1.5 Removal of Sound Blanket / Thermistors.............................................118
1.6 Removal of Four Way Valve.................................................................120
1.7 Removal of Electronic Expansion Valve...............................................121
SiBE07-618_C
Table of Contents
